4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
Specifications
Brand Name :
XUWEN
Model Number :
4S-24S Lithium BMS System
Certification :
CE,FCC,RoHS,UN38.3,MSDS
Place of Origin :
China
MOQ :
5pcs
Price :
To be negotiated
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
To be negotiated
Packaging Details :
Packed in export carton Box
Min. Line Spacing: :
0.003"
Board Thickness: :
1.6mm
Min. Line Width: :
0.1mm/4mi
Number of layer: :
double or Multi-layer
Min. Hole Size: :
0.25mm
Function: :
Battery Protection Board
Description

100a 120a 150a 160a 4S-24S Lithium BMS System High Current Lifepo4 Pcm/Pcb Board For E-Scooter

Model LWS-24S160A-445(24S) lifepo4
Test No. Test item Details Criterion
1 Voltage Charging voltage DC:86.4v CC/CV
Balance voltage for single cell 3.650±0.025V
2 Current

Balance current for single cell

Current consumption

72±10mA

≤20μA
Maximal continuous charging current 100A
Maximal continuous Discharging current 100A
3 Over charge Protection Over charge detection voltage for single cell 3.90±0.025V
Over charge detection delay time 0.5S—2S
Over charge release voltage for single cell 3.80±0.025V
4 Over discharge protection Over discharge detection voltage for single cell 2.00±0.05V
Over discharge detection delay time 10mS—200mS
Over discharge release voltage for single cell 2.30±0.05V
5 Over current protection Over current detection voltage 0.62V
Over current detection current 600±100A
Detection delay time 5ms—20ms
Release condition Cut load
6 Short protection Detection condition Exterior short circuit
Detection delay time 200-500us
Release condition Cut load
Resistance Protection circuitry(MOSFET) ≤50mΩ
7 Temperature Operating Temperature Range -40~+85℃
Storage Temperature Range -40~+125℃

4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
