Lithium Ion Battery Pack Assembly Line Three Side Top Bottom And Side Sealing Machine
Lithium Ion Battery Pack Assembly Line Three Side Top Bottom And Side Sealing Machine
Specifications
Brand Name :
Honbro
Certification :
CE certification
Place of Origin :
Dongguan, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
lab machine: 7-8 weeks, Mass production machine: 13-14 weeks
Packaging Details :
Fumigation-free wooden box and vacuum moisture-proof treatment
Applicable battery Specifications :
It can be customized
Battery length :
L300-700mm
Battery width :
W400-820mm
Battery thickness :
5-25mm
Description

Three-Side Top And Bottom Side Sealing Machine

Function Description

This device is suitable for heating packaging of top edge, bottom edge and one side of flexible packaging lithium battery, and is compatible with the same side and different side pole ear battery

Technical feature

  • The aluminum plastic film and the cell are equipped with a fixture platform, and the pole ear is equipped with an auxiliary positioning device to ensure the position accuracy of the cell
  • The upper head adopts servo motor drive cylinder package, the lower head cylinder drive, pressure balance can be adjusted
  • The parallelism of the package head is adjusted by pulling the top, which is convenient to adjust the parallelism of the seal and ensure the consistency of the package
  • The pole ear is equipped with independent auxiliary heating device, and the temperature is independently controllable and adjustable
  • The heating device uses the main heating tube and auxiliary heating tube compensation way to control the head temperature; Room temperature -260℃ adjustable, can set compensation, control accuracy ±3℃, high and low temperature alarm function
  • With safety light curtain and double button start, as well as emergency stop button

Technical Parameters: ( the product is constantly upgraded, the following parameters are for reference only )

Item Common Parameter
Applicable battery Specifications It can be customized
Battery length L300-700mm
Battery width W400-820mm
Battery thickness 5-25mm
Edge width 5-10mm
Seal precision ±0.015mm
Equipment capacity 10-30EA/H ( depending on the proficiency of workers and packaging time not more than 5 seconds )
Qualification rate 99%
Action 98%
The equipment size 1900 mm * 3000 mm * 1800 mm
The power supply AC380V,50HZ,8kw
Air supply 0.5 to 0.7 MPA ; 15L/min
