Large Long Lithium Ion Battery Manufacturing Equipment Final Sealing Machine
Large Long Lithium Ion Battery Manufacturing Equipment Final Sealing Machine
Specifications
Brand Name :
Honbro
Place of Origin :
Dongguan, China
Certification :
CE certification
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
7-8 weeks
Packaging Details :
Fumigation-free wooden box + vacuum moisture-proof treatment
Length of the cap :
Length of the cap ≤700mm
Applicable range :
L630XW350(Air bags are included)XT3-15.
Thickness of edge banding :
0.14-0.3mm
Maximum vacuum degree in the cavity :
-0.09 5MPa
Description

Final Sealing Machine For Large And Long Batteries

Function Description

  • The device is designed for the final vacuum pumping sealing package after the electrolyte filling and charging of flexible

packaging lithium battery cells

Technical Feature

  • Sealing parallelism ±0.01
  • Temperature difference in different parts of the cap ±3°
  • Added precision of the cap ±0.008
  • Sealing temperature 0-250°, which is adjustable
  • Final sealing angle 0-20°, which is adjustable
Applicable range L630XW350(Air bags are included)XT3-15.
Length of the cap ≤700mm
Sealing width 5-10mm(Sealing width of accepted products will be provided when an order is placed)
Thickness of edge banding 0.14-0.3mm
Temperature of the cap Room temperature -230℃, which is adjustable. Compensation and control precision can be set
Maximum vacuum degree in the cavity -0.09 5MPa
Sealing time 0-99.9s, which is adjustable
Parallelism of the sealing head ±0.01mm, Triple carbonless copy paper can be used when detecting When the pressure of the head is in 0.6Mpa, and the temperature in 200℃ æ sealing is even
Output 100-200 EA/H
Action 95%
Qualified rate 99%
