Semi Automated Lab Equipment Hot Pressing Hi Pot Tester Lithium Ion Battery Machine Manufacturers
Semi Automated Lab Equipment Hot Pressing Hi Pot Tester Lithium Ion Battery Machine Manufacturers
Specifications
Brand Name :
Honbro
Certification :
CE certification
Place of Origin :
Dongguan, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
lab machine: 7-8 weeks, Mass production machine: 13-14 weeks
Packaging Details :
Fumigation-free wooden box and vacuum moisture-proof treatment
Battery application range :
Lithium batteries
Specification of work table :
350 x 270 mm
Upper and lower template parallelism :
±0.02mm
Template pressure :
Adjustable 50-2000 kg
Description

Hot Pressing Hi-Pot Tester

Functions Description


This equipment is suitable for soft packaging lithium battery and cell hot pressure shaping, HI-POT test


Technical Feature

  • Maximum pressure 2T ( can be customized )
  • The pressure holding time is adjustable, and the down speed is adjustable
  • Maximum size of worktable 350×270mm ( can be customized )
  • At the same time, test whether the short circuit between the polar ears, and measure the internal resistance
  • The hot pressing plate adopts hard copper plate, and the heating function can be turned off

Technical parameters : ( the product is constantly upgraded, the following parameters are for reference only )

Item common parameter
Battery application range Lithium batteries
Specification of work table 350 x 270 mm
Upper and lower template parallelism ±0.02mm
Template pressure Adjustable 50-2000 kg
The holding time Adjustable from 0 to 30 minutes
Hot-pressing temperature Room temperature ~130C adjustable, can set compensation, control accuracy ±3℃, too low, too high with alarm function
Hi- Pot test Hi-pot voltage 0~500V, test time 1.0~ 5.0s, discharge time 1.0~ 5.0s ( optional tester )
