Lab Semi Auto Battery Sealing Machine Degas Machine
Lab Semi Auto Battery Sealing Machine Degas Machine
Specifications
Brand Name :
Honbro
Model Number :
HBS-DGS350 ( TY/QY ) Type
Certification :
CE certification
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
350 sets/year
Delivery Time :
7-8 weeks
Packaging Details :
Fumigation-free wooden box + vacuum moisture-proof treatment
Power :
2.5KW
Power source :
AC380V/50HZ
Output :
2.5-3PPM
Qualified rate :
≥99%
Description

Degas Machine , HBS-DGS350 ( TY/QY ) Type , Lab Semi-Auto Battery Production Equipment

Function Description

  • This device is designed to pierce battery air bags of flexible packaging EV-battery, pump vacuum and seal

Technical Feature

  • Double-station rotating material transfer. Material loading and unloading, and sealing can be done at the same time
  • Turntables, the upper cavity and the lower cavity constitute a closed sealing cavity so as to meet the requirements of vacuum sealing.Electrolyte separation box is equipped. Electrolyte elimination channel is improved to alleviate pollution of vacuum source
  • The machine is controlled by PLC to achieve auto control. A touch screen is equipped to achieve man-machine dialogue, which is convenient for operation
  • Output statistic function is included. Functions of manual and automatic operation are included. Fault alarming function is included
  • Sealing temperature, pressure, time and pump down time can be preset. Temperature abnormal alarm function is included
  • Maintenance air cylinder of the head in the upper cavity is included. When it is in maintenance, the upper head and the knife come out of the cavity, which makes it convenient for maintenance
  • Material transferring turntables is driven by a precision cam wheel splitter. The positioning precision is ≤30'’
  • The parallelism of the upper and the lower head : ±0.01mm. the degree of alignment can be adjusted through regulating mechanism
  • Pressing plate of the battery in the cavity can produce pressure through the air cylinder or spring

Technical Parameters

Item HBS-DGS350(TY/QY)
Measures 1000*900*1650mm(L*W*H)
Weight 约800Kg
Power 2.5KW
Power source AC380V/50HZ
Air source ≥0.6MPa,35L/min
Vacuum source ≤-0.095MPa, 350L/min
Applicable range

"L250mm-300mm

W150mm-200mm

T3.0mm-15mm"
Output 2.5-3PPM
Qualified rate ≥99%
