Multi Section Structure CCD Slitting Machine AGC Car Feeding
Multi Section Structure CCD Slitting Machine AGC Car Feeding
Multi Section Structure CCD Slitting Machine AGC Car Feeding
Multi Section Structure CCD Slitting Machine AGC Car Feeding
Specifications
Brand Name :
Honbro
Model Number :
CCD type
Certification :
CE certification
Place of Origin :
Dongguan, China
MOQ :
1 SET
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
Lab machine:7-8 weeks, Mass production machine:13-14 weeks
Packaging Details :
Fumigation-free wooden box and vacuum moisture-proof treatment
Slitting width :
20～900mm
Machine speed :
1～80m/min
Slitting speed :
1～70m/min
Burr :
≤6um
Capacity :
mass production
Color :
according to customer
Description

CCD Slitting Machine,AGC Car Feeding,Multi-Section Structure Make It More Convenient To Operate And Maintain .

Multi Section Structure CCD Slitting Machine AGC Car Feeding

Functions and Features:

  • CCD detection system: CCD defect detection carries out online detection of the positive and negative parts of the pole plate and automatic labeling of the defective pole plate; CCD width detection and deviation correction automatically adjust the cutting width in a closed-loop;
  • Automatic coil threading mechanism: Equipped with automatically threading function by chains;
  • Unwinding mechanism: Adopt functions of automatic closed-loop tension control system, AVG trolley docking and automatic feeding and unwinding ultrasonic coil diameter monitoring;
  • Dust removal system: Unique negative pressure vacuuming cavity structure with static elimination device;
  • Industrial vacuum cleaner: collecting pole dust, low noise structure, equipped with reverse blowing dust function;
  • Edge material pulling mechanism: Edge materials on both sides are independently and automatically pulling with independent control of tension and separate edge bins automatically collect edge materials;
  • Rewinding mechanism: The upper and lower slip shafts are equipped to ensure the same winding tension of each roll,rewinding automatic pushing and unloading mechanism;
  • Unique slitting knife seat structure ensures quick changeover, and the changeover time is less than 0.5 hours;
  • Optional: Ceramic slitting knife, cursor-assisted positioning for rewinding and unwinding, etc.
  • Multi-section structure make it more convenient to operate and maintain .

Technical parameters( the following parameters are for reference only)

Item Common parameter
Slitting width 20-900mm
Machine speed 1-80m/min
Slitting speed 1-70m/min
Burr ≤6um
Slitting width accuracy ≤0.05mm
Winding edge alignment ±0.4mm
U/W and R/W diameter Max.ϕ800mm
