32700 Cylindrical Cell Case
32700 Cylindrical Cell Case
Specifications
Brand Name :
TICO
Model Number :
STC-CGK-32700
Place of Origin :
Shenzhen
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200000 sets per month
Delivery Time :
5~8 working days
Packaging Details :
Cartoon Packing (Optional according to quantity)
Name :
32700 Cylindrical Cell
Material :
Nickel plated steel
Description

32700 Cylindrical Cell Case

Technical Parameters

Model STC-CGK-32700
Material Nickel plated steel
Height 72.80＋0.05/－0.09mm
Diameter of the case flaring

Mouth outer: 32.34＋0.07/－0.09mm

Inner: 31.50±0.05mm

Outer: 32.34＋0.04/－0.09mm
Diameter of middle part

Outer: 32.20＋0.06/－0.04mm

Inner: 31.50±0.05mm
Diameter of bottom 26.50±0.50
Thickness of case wall

Mouth: 0.42±0.02mm

Middle bottom: 0.34±0.02mm
Thickness of nickel coating

6.0mm away from the outer wall of the case: 2.5~7μm

36.0±5.0mm away from the outer wall mouth of the case: ≥ 2.5μm

16.0mm away from the outer wall edge of the bottom of the case: ≥ 0.25μm

36±5mm away from the inner wall mouth of the case: ≥ 2.5μm
R angle 15±0.08mm
