Supercapacitor Secondary Sealing Machine
Supercapacitor Secondary Sealing Machine
Specifications
Brand Name :
TICO
Model Number :
STC-SEF-60
Place of Origin :
Shenzhen, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15 sets per week
Delivery Time :
8~12 working days
Packaging Details :
Standard export wooden box package
Model :
STC-SEF-60
Power :
0.5KW
Weight :
500kg
Utilization rate :
98%
Description

Supercapacitor Secondary Sealing Machine

Brief Introduction

It is suitable for secondary molding, sealing and crimping of battery and supercapacitor cases.

Key Features

● The annular jacket of mold designed for sealing process, good performance in sealing.

● High precision mold of guide post and sleeve, ensuring the parallelism of the upper and lower molds.

● The mold is controlled by the pressure cylinder to seal cases to ensure the stable output.

● Sealing height, sealing pressure and holding time is adjustable

● PLC control system, high stable and reliable, easy to operate.

● The color LCD touch screen, easier to view parameters.

Technical Parameters

Model STC-SEF-60
Power supply AC220V±10%, 50Hz
Power 0.5KW
Application φ60 battery and supercapacitor cells, the length is H50~240mm, other size can be customized
Dimensional change of the side of the sealed cased ≤±0.03mm
Capacitor height accuracy after sealing HA≤0.1mm
Flange Sealed with a mold
Service life of the tooling and mold ≥5000000 times
Capacity ≥3 pcs
Utilization rate 98%
Air source 0.5~0.7Mpa adjustable
Air consumption 0.4m3/min
Loading Requirements for installation site 0.5T/m2 or above
Working temperature 10~35℃
Humidity 10~80%Rh
Equipment size L600 * W565 * H1750mm
Transportation size L650 * W600 * H1900mm
Weight 500kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
