Prismatic Cell Battery Automatic Layer By Layer Stacker Stacking Machine
Prismatic Cell Battery Automatic Layer By Layer Stacker Stacking Machine
Specifications
Brand Name :
XWELL
Model Number :
XW-PC10
Certification :
CE
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
L/C, D/A, D/P, Western Union, MoneyGram, T/T
Supply Ability :
100 pcs/month
Delivery Time :
10-15 working days
Packaging Details :
Wooden box
Machine Name :
Automatic Stacking Machine
Application :
Li-ion Battery Mfg
Model :
XW-PC10
User interface :
Touch screen software
Driver :
Servo motor
Transmission :
Bearings and screw
Description

Prismatic Cell Battery Automatic Layer By Layer Stacker Stacking Machine

Stacking machine description

This Production Line Sodium ion Battery Lithium ion Prismatic Cell Automatic Stacking Machine is mainly used for zigzag lamination of square lithium-ion power battery cells.

Stacking machine features

The diaphragm is automatically unwound, and introduced into the lamination table through the roller with constant tension. The lamination table drives the diaphragm to move back and forth. The suction cups take out the positive and negative plates from the feed tank respectively. After CCD positioning correction, they are placed on the lamination table. Once it achieves a pre-set number of layers, the diaphragm is thermally cut off (leaving a small amount of tailings). And then the cells are transferred to the gluing mechanism by the manipulator; After that, the glued cells will be transferred to the stacking platform by the manipulator.

Stacking machine specification

Item Name Parameter
1 Model XW-PC10
2 Max travel 1000mm
3 Control system PLC
4 User interface Touch screen software
5 Driver Servo motor
6 Transmission Bearings and screw
7 Pressure measure High precession pressure sensor
8 Position accuracy 0.01mm
9 Pressure accuracy 0.1kg
10 Power supply AC220V/50Hz
11 Power 2KW
12 Size 1500*500*1500mm
13 Weight 200kg

Stacking machine details

Prismatic Cell Battery Automatic Layer By Layer Stacker Stacking MachinePrismatic Cell Battery Automatic Layer By Layer Stacker Stacking MachinePrismatic Cell Battery Automatic Layer By Layer Stacker Stacking Machine
