Specifications
Brand Name :
JWSY
Model Number :
AD-SM15
Place of Origin :
China
MOQ :
10 units
Payment Terms :
Payment before delivery
Supply Ability :
10000 units
Delivery Time :
10 Work days
Packaging Details :
Carton packaging
Device Name :
Integrated Reader
Size :
445x445x74MM
Group read performance :
>20 tags
Identification distance: :
0-15m
Operating voltage :
9-12V
Working Current :
200MA
Description
▋915M Long-distance Integrated Reader

AD-SM15 is a fixed and compact reader, compatible with ISO 18000-6C standards, its working frequency of 860MHz ~ 9608MHz, compact appearance, excellent reading and writing performance. The reader can be widely used in warehouse logistics management, retail logistics center management, enterprise transportation management, automatic production line management and other fields.

915M Long Distance Integrated Reader 860MHz - 9608MHz For Warehouse Logistics Management

▋Technical Specifications

Functional features

System parameters:

ARM7+UHF modules

Working frequency:

National standard(920～925MHz)

US standard(902～928MHz)

European standard(865～868MHz)

Other multinational frequency standards (customized)

Identification distance:

0-15m

Group read performance:

>20 tags

Label protocol:

Support ISO18000-6C (EPC GEN2) protocol electronic tags

Frequency hopping mode:

Wide spectrum frequency hopping (FHSS) or fixed frequency, can be set by software;

Way of working:

Automatic mode, trigger mode, interactive mode, etc

Rf Power:

0-30dBm (power software adjustable)

Antenna parameters:

12dBi Linearly Polarized Antenna (built-in)

Supported interfaces:

Standard RS232, RS485, Wiegand26, Wiegand34,

optional RJ45, WIFI, GPRS, etc

Operating voltage:

9-12V ；

Working current:

200MA；

Recognition Tips:

Beep or LED flash

Power consumption:

<4W

Work environment

Operating temperature:

－20℃ ～ +70℃(Beyond the scope need to customize)

Working humidity:

20％ ～ 95％(no condensation)

Storage temperature:

－40℃ ～ +125℃

Physical parameters

External dimensions:

445x445x74MM

Net weight:

4.0KG

Gross weight:

5.0KG

Other Notes

Secondary development:

Dynamic link library (DLL) and demo software source code are provided to support secondary development.

Note:

The recognition distance and group reading performance need to depend on the tag performance and the specific application scenario, and can be customized according to requirements

▋Product features

  1. Low power, stable and reliable read/write distance;

    Fast data read rate;

    Tag wake-up recognition;

    Multi-region multi-label reading;

    Multi-protocol compatibility;

    Waterproof appearance design;
