Specifications
Infrared sensor :
4 Pairs
Model Number :
KMS-B8420
Channel Width :
550mm-1000mm
MOQ :
1 pcs
Delivery Time :
5-14 work days
Packaging Details :
Wooden Case Package
Product Name :
Swing Turnstile
Price :
USD560-USD1100
Supply Ability :
1000peices/Month
Passage Frame :
304 Stainless Steel / 201 Stainless Steel With Baked Paint
Certification :
CE | RoHS
Payment Terms :
T/T
Product Size :
1400mm*180mm*1000mm
Brand Name :
Kemaisi
Product Power :
100W
Place of Origin :
Guang Dong China
Description

Scenic Spot Ticket Entry Management Swing Gate Turnstile

Product Description


Parks , scenic spots , zoos , and outdoor playgrounds often face visitor complaints due to ticket checking congestion during peak holidays . At the same time , they need to handle the tedious reconciliation of multiple channels such as online platform purchases , group buying , annual passes , and paper tickets . Manual ticket checking also easily leads to ticket evasion or ticketing disputes . This intelligent turnstile provides a one stop solution : it supports multiple credentials such as QR code , ID card , facial recognition , and annual pass , completing ultra fast ticket verification and passage within 1 second . The system integrates data from all ticketing channels , allowing managers to grasp real time ticketing and visitor flow information with just a mobile phone . The dual verification technology of dynamic QR code and facial recognition effectively prevents forged tickets or identity fraud . The device has built in fault self diagnosis and alarm functions for easy daily maintenance . In the event of a power failure , the turnstile automatically triggers fire mode , sounds an alarm , and immediately opens the gate , ensuring unobstructed emergency evacuation of visitors .


Features and Advantages

1 . Ultra fast ticket verification and passage

Supports multiple credentials such as QR code , ID card , facial recognition , and annual pass . Verification and gate opening are completed within 1 second , effectively reducing queue congestion during holidays and improving visitor satisfaction .


2 . Unified multi channel management

Integrates data from all ticketing channels including online platforms , group buying , annual passes , and paper tickets . A single mobile phone allows real time viewing of ticketing and visitor flow information , eliminating tedious reconciliation .


3 . Intelligent anti forgery dual verification

Dual verification of dynamic QR code and facial recognition eliminates forged tickets or identity fraud , protecting scenic spot ticket revenue .


4 . Fault self diagnosis and alarm

Built in self diagnosis module triggers an automatic alarm when an abnormality occurs , helping maintenance staff quickly locate problems and reducing equipment downtime .


5 . Power failure fire safety protection

In the event of a power failure , the turnstile automatically triggers fire mode , sounds an alarm , and immediately opens the gate , ensuring rapid evacuation of visitors and meeting fire safety requirements .


Product Name Swing Turnstile
Barrier Material Acrylic Swing Arm
Passage Frame 304 Stainless Steel / 201 Stainless Steel With Baked Paint
Product Size 1400mm*180mm*1000mm (Sizes Can Be Customized)
Traffic Speed 30 People/Minute, Normally Open 40 People/Minute
Service Life ≥5 Million Times
Channel Width 550mm-1000mm
Working Voltage AC220V±10%/50HZ 50W
Relative Temperature ≤95% Not Condensing
Product Power 100W
Weight 40-65KG
Opening Time 0.5 Seconds
Ambient Temperature -30℃-70℃
LED indicator lights 2
Work Environment Indoor And Outdoor
Protection Grade IP43, IP54
Infrared sensor 4 Pairs
Access Control Type RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening
Communication Interface Relay switch signal/12V level signal/12V pulse signal with pulse width>100ms; RS485 or TCP/IP


Scenic Spot Ticket Entry Management Swing Gate Turnstile


Frequently Asked Questions

Q1:Can this swing gate integrate with third-party access control systems?

Yes. It supports TCP/IP, RS485, Wiegand, API, and SDK integration, making it compatible with most mainstream access control systems.


Q2:Can the gate be installed outdoors?

Yes. An IP65 outdoor version is available for projects requiring weather-resistant performance.


Q3:Which authentication methods are supported?

The gate supports Face Recognition, RFID Cards, QR Codes, Fingerprint, NFC, Bluetooth, and Mobile APP access.


Q4:Is OEM or ODM customization available?

Yes. We provide full OEM & ODM services, including cabinet dimensions, colors, logos, access terminals, software integration, and branding.


Q5:What happens if the power goes out?

The barriers automatically unlock to provide safe emergency evacuation and comply with international fire safety requirements.
