Automatic Peanut Bar Making Machine
Product Overview
Peanut bars are delicious and nutritious snacks made primarily from peanuts, combined with sweeteners like sugar, honey, or caramel, and other ingredients such as seeds, chocolate, or dried fruits. These bars are popular for their high protein content, energy-boosting properties, and satisfying crunch.
The Hanyuan Automatic Peanut Bar Making Machine is a fully automated system designed to manufacture peanut-based snack bars, energy bars, and candy bars with consistent quality and high efficiency.
Production Line Components
Finished Product Sample
Complete Machine Configuration
 |  |  |
| Roasting Machine | Peanut Peeling Machine | Sugar Cooking Equipment |
 |  |  |
| Mixing Machine | Cutting Machine | Packaging Machine |
Key Features
- Automatic material preheating and proportioning system with integrated cooking pot mixing
- Three-roll feeding hopper for even material distribution
- Combined fan-cooling and water-cooling system for uniform cooling from bottom to top
- Vertical and transverse cutting integrated cutter-head for precise sizing and complete bar separation
- Fully automatic pillow packaging with fast sorting and high-speed packaging capabilities
Technical Specifications
| Parameter | Value |
| Voltage | 380V/50Hz |
| Power | 150kW |
| Capacity | 300-500kg/h |
| Floor Area | 30×6m |
| Manpower Required | 4-6 people |
