Specifications
Brand Name :
YJFIRST
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
$32
Payment Terms :
T/T
Supply Ability :
20000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
Gift box
Product name :
QR Scanner Box
private mold :
Yes
Application :
Supermarket/retail chain
Scan Mode :
Continuous Scanning
Single package size :
15X10X10 cm
Single gross weight :
0.300 kg
Description

Desktop Barcode Reader Payment Box QR Code Platform 2D Android Barcode Scanner for Alipay Mobile

Physical Design & Placement:

Stationary: Designed to sit fixed on a countertop, desk, kiosk, or work surface.

Compact Form Factor: Typically low-profile, taking up minimal desk space.

Reading Window/Aperture: A designated area (usually on the top or front) where codes are presented. This window

houses the imaging sensor and illumination system.

Mounting: Often includes rubber feet for stability. Some models have optional mounting brackets for vertical surfaces

or integration into kiosks.

Durability: Generally robust for commercial/industrial environments. Many feature rugged casings.

Typical Application Scenarios

Retail & Hospitality

Point-of-Sale (POS) Systems:
Scan product barcodes (UPC/EAN) for instant pricing and inventory deduction.
Process QR-based loyalty cards, coupons, or mobile payments (e.g., WeChat Pay/Alipay).

Self-Checkout Kiosks:
Enable customers to scan items autonomously.

Inventory Management:
Track expiry dates or restock levels by scanning warehouse item labels.

Logistics & Warehousing

Parcel Sorting Hubs:
Read shipping labels (Code 128/Code 39) to automate routing.

Receiving/Shipment Stations:
Update Warehouse Management Systems (WMS) by scanning pallet/box IDs.

Smart Locker Systems:
Validate pickup codes for contactless package retrieval.

Healthcare

Pharmacy Operations:
Verify drug serialization codes (Data Matrix) for safety compliance.

Patient Check-In:
Scan health insurance cards/ID QR codes to pull electronic health records (EHR).

Lab Sample Tracking:
Link specimen tubes to test orders via barcodes.

Parameter

Scan Type CMOS
Light Source Red Light LED 625±10nm(aim), 5600K LEDs( Lighting)
CPU 32-bit
Field of view 60°(H)x48°(V)
Resolution 640*480
Resolution ≥5mil/0.127mm(PCS90%,Code 39)
Decoding speed 25CM/S
Depth of field 10mm-200mm
Scan Mode Auto Sense
Scan angle Roll±360°, Pitch±65°, Skew±60°(PCS90%, Code 39, 10mil/0.25mm)
Print Contrast Signal ≥25%
Ambient Light Dark environment, indoor natural light
Symbologies 1D: UPC-A,UPC-E,EAN-8,EAN-13,ISSN,ISBN,Code 128, GS1-128,ISBT 128, Code 39,Code 93,Code 32, Code 11, Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),Plessey,MSI Plessey,GS1-Databar(RSS),Itf-14,etc.
2D: QR Code, Data Matrix, PDF 417, Aztec Code, Maxicode, Hanxin. etc.

Weight ≈156g (no Cable)
Dimension (L)120mm * (W)90mm *(H)76mm
Interface Type Type B
Communication Mode USB,RS232
Power Supply DC 5V@120mA(Max),100ma(work)

Operating temperature -20℃ to 50℃
Storage temperature -40℃ to 70℃
Humidity 5% to 95%(non-condensing)
Drop Height 1.2m
Temp. Test 30 minutes for high Temp., 30 minutes for low Temp.,
High Temp. 60℃
Low Temp. -20℃
Transport vibration Test 10H@125RPM
