Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Table Mounted QR Code Reader Customized Table Top Scanner Professional
Specifications
Brand Name :
YJFIRST
Model Number :
YJ-5012
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
China
MOQ :
1Pcs
Price :
1 - 100 pieces $18 100 -500 pieces $17 500 -1000 pieces $16
Payment Terms :
T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
Supply Ability :
20000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
box
Product name :
QR Code Reader
Type :
Barcode Scanner
Status :
stock
Weight :
205.5g
LED :
White fill-in light
Scan type :
Paper and screen
Description

High Quality 1d 2d Qr Code Reader Barcode Scanner Table Mounted Barcode Scanner

Products Description


Description:


The YJ5012 is a professional 2D scanning platform designed to read 1D and 2D barcodes from various screen brightness

levels on mobile phones.Supports rapid recognition of 1D/2D barcodes and QR codes with industry-leading decoding

accuracy.Fast checkout at POS counters for scanning product barcodes (UPC/EAN), QR codes, and digital payment links.


Features:


☆High-performance MCU to easily identify the mainstream 1d or 2d barcode.

☆ Read barcodes above 4mil to meet the need of daily scanning.

☆ 2d imaging technology, support paper, printing, plastic, screen barcode.

☆Wide scanning range (front/side/top) with automatic multi-angle detection for efficient checkout.

☆ Supporting both independent desktop placement and embedded installation, it can be seamlessly integrated into self-service
terminals, POS machines and other equipment.

Parameter:


Ability to read
Identification accuracy
≥5mil
Read the way
Close to, close to the reading
Scan the Angle
The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
Support code system
In line with the international and domestic general QR code standards:
QR Code, PDF417, DataMatrix), etc
In line with the international and domestic general one-dimensional code standards:
EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
Print contrast
Minlowest 25% reflection difference
Interface
Standard USB
Scan pattern
Induction mode / command mode
Read success tips
LED, buzzer or speech
Data wire
1.5 m USB straight line
Electrical parameters
Input voltage
5V (customizable 3.3V)
Working current
130mA (with no voice broadcast) / 380 mA (with voice broadcast)
Standby current
85m A



Table Mounted QR Code Reader Customized Table Top Scanner Professional

Table Mounted QR Code Reader Customized Table Top Scanner Professional

Table Mounted QR Code Reader Customized Table Top Scanner Professional

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.

Q: What's the payment method?
A: We accept online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
