Low-Power Embedded 2D Barcode Scanner Perfect for Battery Powered IoT Modules

Specifications

Brand Name :

YJFIRST

Model Number :

YJ-ES215

Certification :

CE, ROHS, FCC, IEC, FDA

Place of Origin :

Guangdong, China

MOQ :

1Pcs

Price :

1 - 100 pieces $18 100 -500 pieces $17 500 -1000 pieces $16

Payment Terms :

T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union

Supply Ability :

20000pcs/month

Delivery Time :

3-7 work days

Packaging Details :

Gift box

Product name :

Low-Power Embedded 2D Barcode Scanner

Size :

5.4*3.4*0.9cm

Weight :

12g

interface type :

Usb, TTL

Scan Mode :

Command Mode / Sensing Mode / Trigger Mode

color :

White

Installation :

No Driver, plug and play

Description

Low-Power Embedded 2D Barcode Scanner Perfect for Battery Powered IoT Modules

Features of Embedded 1D/2D Barcode Scanners

YJ-ES215 stands out as a highly integrated identification module with comprehensive functions. It combines exceptional barcode

scanning and digital image acquisition capabilities, along with an ultra-thin design and extensive compatibility, enabling flexible

integration into diverse terminal devices.

Advantages of Embedded 1D/2D Barcode Scanners

1.Decoding Technology: Utilizes independently developed core decoding algorithms and a 300,000-pixel recognition

resolution, guaranteeing fast reading speed and high precision.

2.Streamlined Development Experience: Supports secondary development and delivers an SDK package compatible with

multiple operating systems, minimizing the complexity of system integration.

3.Versatile Interface Options: Equipped with USB and TTL interfaces to satisfy the routine connection demands of modern

terminal equipment.

4.Innovative Design: Features an ultra-thin structure and maintains efficient barcode reading performance even under harsh

outdoor lighting conditions such as strong direct sunlight or backlighting.

5.Comprehensive Recognition Capability: Powered by proprietary core decoding technology, it stably and quickly decodes

barcodes of all quality types—encompassing 1D/2D codes on paper or digital screens, from ordinary barcodes to mobile

device-generated QR codes—with accurate identification.

6.Ultra-Slim & Integrated Construction: Boasts an 8.3mm ultra-thin design with high integration, facilitating easy installation

and embedding into various terminal devices.

Embedded 1D/2D Barcode Scanner Product Application Scenarios

Extensively integrated into various terminal devices across the IoT ecosystem, including self-service vending machines,

self-service information kiosks, smart logistics parcel lockers, queue management systems, self-service ticket dispensers,

and POS payment terminals.

Embedded 1D/2D Barcode Scanner Product Specifications

Capability
Collection method	Image type, CMOS Sensor
Picking rate	1 / 60 Seconds
Field of view Angle	Diagonal is 73°, 61° horizontal, and 48° vertical
Ability to read
Read the way	Close to the approach window, you can move the reading
Scan depth of field	test condition	depth of field
	ITF 18bytes 7.5 mil commodity code	50~130mm
	Code 39 4mil 10B	40~100mm
	Code 128 14mil 17B (SF number)	85~300mm
	QR Code 35mil (WeChat payment code)	25~440mm
Scan the Angle	The angle is 360°, elevation ± 60°, and bias ± 60°
Support code system	In line with the international and domestic general QR code standards: QR Code, Data Matrix, PDF417, Hanxin, Dotcode, et al
	In line with the international and domestic general one-dimensional code standards: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128,ISBT 128, Code 39, Code93, Code 11, Interleaved 2 of 5,Industrial 2 of 5,Matrix 25, Standard 25, Codabar, MSI / MSI PLESSEY, GS1 DataBar et al
LED
Fill-in light	White
Physical parameters
Size (cm)	5.43.40.9 (length, width and height)
Weight	12g

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us

for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents

you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,

shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
