Specifications
private mold :
Yes
products status :
Stock
type :
Barcode Scanner
scan element type :
CMOS
colour depth :
32 Bit
interface type :
usb
max paper size :
A4 Size
Brand Name :
WCMI
Place of Origin :
Tianjin, China
warranty(year) :
15 months
after-sales service :
Return and Replacement, Others, Repair, Free spare parts, Onsite Training and Inspection, Call Center and on-line Technical Support
software development kit (sdk) :
NO
color :
Gray, Black, White
sensor :
CMOS 640*480
Light source :
Red LED
View Angle :
Horizontal 44°, Vertical 34°
Scan Angle :
Rotation: 360°, Pitch: 60°, Deflection: 60°
Scan Mode :
Induction mode
Precisions :
1d ≥4mil / 2d ≥10mil
Symbol Contrast :
≥15%
Weight :
<350g
Dimension :
150.32mm x 95.6mm x 88.88mm
Description
Product Description
SD5637 omnidirectional barcode scanner is the perfect blend of affordability, performance and style. SD5637 adopts the 4th Generation I-SUBPIXEL Algorithm, which can easily read paper barcodes and screen barcodes at high speed. It adopts a new generation of lighting design with cool lighting prompt function. The SD5637 is a plug-and-play scanner, and installing it into existing checkout systems is easy. It can be widely used in supermarkets, restaurants, cinemas, pharmacies and other industries.
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
Product Parameters






General
Type
Wire Desktop Barcode Scanner Platform
Product Model
SD5637
Brand Name
WCMI
Products Status
Stock
Place of Origin
Tianjin,China
Private Model
Yes
Warranty
15 months
After-sales Service
Return and Replacement; Free spare parts
Certification
RoHS、FCC、CE
Color
Black
Language Supported
English/Customized
Scan Element Type
CMOS






Scan Code
Performance
Image (Pixels) Sensor
640 X 480 CMOS @ 100fps
Light Source
Red LED
View Angle
Horizontal 44°, Vertical 34°




Decoding Capability
2d: QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417
1d: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar 、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、MSI
Plessey 、RSS-14、RSS-Expand、RSS-Limited、Standard 2 of 5、Code 16K、Plessey、ChinaPost、Code49


Depth of Field
Code39: 0~50mm （5mil）
EAN13: 0~130 mm （13mil）
CODE128: 0~180 mm （15mil）
Wechat Payment(6 inch):0-230mm(TBD)
Scan Angle
Rotation: 360°, Pitch: 60°, Deflection: 60°
Scan Mode
Induction mode
Precisions
1d ≥4mil / 2d ≥10mil
Symbol Contrast
≥15%


Physical
Parameters
Weight
<350g
Dimensions
150.32mm x 95.6mm x 88.88mm
Interface
USB
Prompt Mode
LED prompt and buzzer
Voltage
DC+5V ±5%
Line Length
1.5m
Current
400mA

Environmental
Parameter
Operating Temperature

-20℃ ~ 60℃
Storage Temperature

-40℃ ~ 70℃
Operating Humidity

5%RH~95%RH (Non-condensing)
Company Information
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
Tianjin wavecreating Micro Intelligennt Technology CO., Ltd. is one of the leading professional R&D manufacturers for barcode scanning products in China. Our company is located in Tianjin Economic and Technological Development Area and has a registered capital of 10 million yuan. The company continuously insist on defining products from the chip, taking customized chips, image recognition algorithms and customized services as our core competency and consistently strive to improve it. The company has more than 50 employees, including 36 R&D staff, 97% of whom have a bachelor’s degree or above, 9 masters, and 2 doctors.
Packing & Delivery
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
Certification
A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
FAQ
1. Is OEM or ODM available?
Yes. We are the factory directly. We can make it as your requirement.
2. What’s the warranty policy for the barcode scanners?
We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is
necessary for replacement or new barcode scanners replacement in the next order.
3. Why so competitive?
We have a professional R & D team and technical team and have a large domestic market. So large quantity will reduce our raw material cost directly. What's more, we have mature technology to save costs.
4. How to control the performance stability?
We take the flow line production in the whole processing. Every product will test 4 times at least before it is delivered.
5. How about the factory?
We have more than 200 workers with an advanced dust-free plant. We are approved the new high-tech enterprise by the government. Owned many technical and design patents in different professional fields.
