Specifications
Brand Name :
ACBB
Model Number :
71818 C P4A GA
Certification :
ISO9001 IATF16949
Place of Origin :
China
MOQ :
30 PCS
Packaging Details :
Company brand packaging.
Product name :
Angular Contact Ball Bearing
Product model :
71818 C P4A GA
Characteristic :
High speed and high rigidity
Rotational speed :
9500RPM-11000RPM
Angle :
C/CD/AC/A5/ACD/A5/E
Preload :
Light preload
Rolling Body :
Steel Ball
Holder :
Bakelite holder
Description

Angular Contact Ball Bearing 71818 C P4A GA (in addition to DB, DT, TBT, QBC and other matching methods) is mainly used on high-speed motor spindles. The operating speed reaches 9500 to 11000 rpm. Imported materials, imported G5 grade steel balls, and Kluberspeed NBU15 grease are used, which have the advantages of high rigidity, high precision, high speed, etc.

718 Series Angular Contact Ball Bearing
Bearing No Dimensions(mm) rsmin rs1min (KN) BasicRatedload (RPM)
Ball speed limit		 (RPM) Ceramic Ball limit speed (N) Preload
d D B Cr Cor Grease Lubrication Oil Lubrication Grease Lubrication Oil Lubrication A B C
71816C 80 100 10 0.60 0.30 14.60 16.60 12000 19000 16000 26000 53 216 474
71816AC 80 100 10 0.60 0.30 13.70 15.60 11000 18000 13000 20000 84 302 712
71817C 85 110 13 1.00 0.30 21.60 24.00 11000 18000 14000 22000 93 344 739
71817AC 85 110 13 1.00 0.30 20.40 22.40 10000 17000 12000 19000 113 507 1142
71818C 90 115 13 1.00 0.30 21.20 23.60 11000 18000 14000 22000 91 337 724
71818AC 90 115 13 1.00 0.30 20.00 22.00 9500 16000 12000 19000 110 495 1116

71818 C P4A GA
