220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
Specifications
Product name :
Planetary Ball Mill
Voltage :
220V
Output (kg/h) :
1 - 100 kg/h
Feeding Size (mm) :
1 - 100 mm
Output Size (mesh) :
45 - 12500 mesh
Range of Spindle Speed(r.p.m) :
420 - 512 r.p.m
Weight (KG) :
92 KG
Warranty of core components :
1 Year
After-sales Service Provided :
Video technical support
MOQ :
1 Set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000 Set / Month
Delivery Time :
3-7 Days
Place of Origin :
Hunan, China
Brand Name :
Kingda
Packaging Details :
PE Foam + Cartons / Wooden cases
Price :
Negotiable
Certification :
CE ISO
Description
0.2L / 0.5L / 1L / 2L Lab Horizontal Ball Mill Full Automatic
0.4L Ceramic Ball Mill 220V Desktop Laboratory Grinding Equipment

Product Overview
  • The Vertical Planetary Ball Mill is an essential device for high-tech materials mixing, fine grinding, sample preparation, new product development, and small batch production
  • With compact design, high efficiency, low noise, and versatile features, this mill is ideal for research institutions, universities, and enterprise laboratories requiring precision in sample preparation
  • Features four ball grinding tanks installed on one turnplate that creates planetary movements for high-speed grinding and mixing
  • Capable of processing various materials and granularities using dry or wet methods, achieving minimum particle sizes down to 0.1 micron
  • Widely used in Geology, Mining, Metallurgy, Electronics, Construction Materials, Ceramics, Chemical Engineering, Light Industry, Medicine, and Environmental Protection
  • Designed with comprehensive safety features and stable 220V power supply performance

Applications
  • Materials Research and Development: Crucial for mixing, fine grinding, and new product development of high-tech materials, enabling rapid production of samples with high purity and precise particle size
  • Laboratory Sample Preparation: Ideal for universities, research institutions, and enterprise laboratories, capable of processing four samples simultaneously to enhance experimental efficiency

Technical Specifications
Drive Mode gear drive / belt drive
Operation Mode 2 / 4 grinding tanks working together
Maximum Loading Capacity 2/3 of the capacity of milling tank
Feeding Granularity soil material ≤10mm, other materials ≤3mm
Output Granularity Minimum 0.1um
Rotational Speed Ratio 1:2 (0.4L,2L,4L); 1:1.5(12L,20L)
Rotation Speed 0.4L: 0~600 rounds/min; 2L: 0~580 rounds/min; 4L: 0~530 rounds/min; 20L: 0-280 rounds/min
Speed Regulation Mode Variable-frequency control and program-control stepless speed regulation; manual or automatic timing; forward or reverse rotation
Max. Continuous Operating Time (full-load) 72 hours
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

Planetary Ball Mill Models
Model Specification Capacity Range Quantity
KD-XQM-0.4L 0.4L 50-100ml 4 mill tanks
KD-XQM-1L 1L 50-250ml 4 mill tanks
KD-XQM-2L 2L 560-500ml 4 mill tanks
KD-XQM-4L 4L 50-1000ml 4 mill tanks
KD-XQM-8L 8L 0.5-2L 4 mill tanks
KD-XQM-12L 12L 1-3L 4 mill tanks
KD-XQM-16L 16L 1-4L 4 mill tanks

Key Features
  • Stable gear transmission ensures consistent and repeatable experimental results
  • Planetary movement principle delivers high speed, energy efficiency, and fine particle size reduction
  • Simultaneous processing of four different powder samples
  • Frequency converter control with under-voltage and over-current protection
  • Programmable operation modes including timing, directional control, and rotation patterns
  • Low center of gravity, stable performance, compact structure, and easy operation
  • Integrated safety switch prevents operation when safety cover is open
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

Packaging & Shipping

Packaging Type: PE Form + Cartons / Wooden cases; Custom packaging available

Port: Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port

Delivery Time: Within 3-7 working days from payment receipt

220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

Manufacturing Facility
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

Frequently Asked Questions

Q: What is the size in your products?

A: The minimum type is 0.4L planetary ball mill Model XQM-0.4A (53×30×34cm, 26kg). Models available from 0.2L to 100L capacity.

Q: What is your terms of delivery?

A: FOB, CFR, CIF.

Q: Can you accept small quantity sample order before production?

A: Yes, samples available for testing with customer covering courier costs.

Q: What is your production time?

A: Generally 3-7 days after receiving advance payment, depending on order specifics.

Q: What is your terms of payment?

A: T/T 30% deposit, 70% balance against B/L copy, or 100% L/C at sight.

Q: What is the working principle of planetary ball mill?

A: Working principle of planetary ball mill


Customer Service
  • Custom grinding balls available according to specifications
  • Comprehensive pre-delivery testing of all goods
  • Dedicated customer support with 12-hour response guarantee
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

About Kingda Ceramic Technology
  • Manufacturer of Grinding Media Balls, Grinding Jars, Zirconium Dioxide, and Zirconia structures
  • Committed to quality with high reputation among domestic and international customers including University of Oxford, Loughborough University, Peking University, and Tsinghua University
  • Dedicated to providing high-quality grinding products and exceptional services
  • Focus on mutual benefit and sustainability in business partnerships
220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment 220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment
