Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media
Specifications
Type :
Ceramic Balls
Application :
Industrial Ceramic
Material :
Zirconia Ceramic
Color :
Gold
Shape :
round
Density :
6.0g/cm3
Certificate :
ISO
Size :
0.4-10mm
Raw material :
80%ZrO2+20%CeO2
Feature :
High Wear-resistance
Product name :
Ce-tzp/ceria stabilized zirconia ball/beads for grinding and milling
Port :
shanghai,guangzhou,shenzhen
Place of Origin :
Hunan, China
Model Number :
0.1-50MM
Brand Name :
Kingda
Packaging Details :
25KG/drum / 500-1000KG on pallet with shrink wrapped
Supply Ability :
10 Ton / Month
MOQ :
1 KG
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
3-7 Days
Description



Ce-tzp/cerium oxide stabilized zirconia balls/beads for grinding and milling



Composition

 wt%

 ZrO2 :18~80%
 CeO2:12~20%

 Packed Density

 Kg/L

 3.8(Φ7mm)

 Specific Density

 g/cm3

 5.95~6.0

 Hardness(HV)

 GPa

 >9

 Elastic modulus

 GPa

 200

 Thermal Conductivity

 W/m.K

 3

 Crushing Load

 KN

 ≥10 (Φ7mm)

 Fracture Toughness

 MPam1-2

 8.5

 Grain size

 µm

 ≤0.5

 Thermal expansion
 Coefficient(20-400 °C)

 10x10 -6 / °C(20-400)

 9.0





Size (mm)Size (mm)Size (mm)Size (mm)Size (mm)
0.3-0.51.0-1.21.8-2.02.6-2.85
0.4-0.61.2-1.42.0-2.22.8-3.010
0.6-0.81.4-1.62.2-2.43.0-3.515
0.8-1.01.6-1.82.4-2.63.5-4.0according to client's reqeust



 Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media





Features:

A. Long lifespan: 30 times longer life than glass beads, 6 times than zirconium silicate beads.



B.High efficiency: around 6 times higher than glass beads; 2 times than zirconium silicate beads.



C. Excellent wear resistance and fracture toughness is especially suited for high-solid-phase high viscosity, high hardness of the paste for grinding and dispersing of pure; good match at the same

 time high input energy and the high shear machine sanding.



 Applicalble industry:

     It is suitable for milling and dispersing high viscosity pastes such as paper        making, textile,  dyeing, screen printing inks, offset inks, CaCO3, metal minerals;

 and high purity products ,such as chemical and specialty materials.

Application Fields:



   1.  Painting,Ink,Coating

   2.  Ceramic Inks & Electronic Paste

   3.  Refractory materials,Magnetic materials

        Dye,Pigment,Textile,Printing

   4. Personal Care & Agrochemical





Packaging & Shipping



 Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media



Related Products




Company Information



Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media

Our Services



Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media

Ce-Tzp Zirconia Grinding Balls Ceria Stabilized Cerium Oxide Media



FAQ



1.What's product your company supply?

  A.We can supply yttrium stab.zirconia bead,cerium stab.zirconia bead,zirconia silicate  bead,high alumina ball, agate ball, ball mill grinding jar,tungsten carbide ball, zirconium powder,ceramic structual elements etc.



 2. Q: What is your MOQ?
 A: 1KG. We accept smaller quantity but the cost is higher.



 3. Q: Can you provide complimentary samples?
 A: Yes, the buyers just afford shipping cost .



 4. Q: What is your production time for bulk order?
 A: 7~30 days, according to order quantity.



 5. Q: What is your normal package?
 A: Woven bag or barrel ,drum,carton box and pallet.



 6. Q: What is your payment term?
 A: T/T 30%-70% Deposit, balance against copy of B/L.

 L/C at sight,Western Union, paypal,Visa,etc
