Specifications
Precision rating :
P0/P6
Model Number :
MCF 47 S
Roller Width :
W=24 mm
Payment Terms :
T/T,,
Roller Outer Diameter :
D=47 mm
Supply Ability :
100000 Sets per month
Seals type :
Sealed
Stud Thread :
M20×1.5
MOQ :
1 PCS
Delivery Time :
3-5 working days
Appliion :
Automation Equipment, Conveyors, Printing Machinery, Packaging Equipment
Price :
USD 0.50 to 1.00
Bearing Type :
Track Roller Bearing
Packaging Details :
in individual packing box
Number of row :
Single Row
Brand Name :
GQZ /OEM
Bearing Model :
MCF 47 S
Certifiion :
ISO9001:2015
Material :
GCr15 Chrome Bearing Steel
Place of Origin :
China
Description
MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

Product Overview
  • MCF 47 S is a stud type cam follower with crowned outer ring, adopting full complement needle roller structure. Equipped with integrated threaded stud and sealing assembly, this track roller can withstand heavy radial loads. The crowned outer surface compensates minor misalignment during operation. Made of high-quality GCr15 bearing steel, it supports relubriion and serves as a reliable motion component for automated machinery, conveying and cam drive systems.
Key Specifiions
Bearing Specifiions
Product Name MCF 47 S Crowned Stud Type Cam Follower
Model Number MCF 47 S
Bearing Type Track Roller Bearing
Roller Outer Diameter D=47 mm
Roller Width W=24 mm
Stud Thread M20*1.5
Material GCr15 Chrome Bearing Steel
Load Type Heavy Radial Load
Seal options Sealed
Lubriion Type Grease Lubriion
Limiting Speed(Grease) 2600 r/min
Appliion Automation Equipment, Conveyors, Printing Machinery, Packaging Equipment
Main Features
  • Full complement needle roller design for high radial load capacity
  • Crowned outer ring reduces edge stress and accommodates slight misalignment
  • Built-in sealing structure to block dust and moisture contamination
  • Threaded stud mounting design for simple installation
  • Relubriion port enables regular maintenance and extended service life
  • Manufactured from heat-treated GCr15 chrome bearing steel with high wear resistance
Typical Appliions
  • Automated assembly equipment
  • Conveying and material handling systems
  • Packaging machinery
  • Printing machinery
  • Cam drive mechanisms
  • Automated production lines
Our Products

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

Why Choose GQZ Bearing
  • Strict raw material inspection and standardized heat treatment for stable quality
  • Precision machining ensures dimensional accuracy and interchangeability
  • Complete cam follower series, sufficient inventory for samples and bulk orders
  • Professional technical support for model selection and appliion advice
  • Direct factory price and reliable delivery schedule

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

MCF 47 S Crowned Stud Type Cam Follower Bearing 47mm Metric Sealed Full Complement Needle Roller Track Roller

FAQ
Q1: What is the thread specifiion of MCF 47 S?
A1: Stud thread: M20*1.5; roller outer diameter: 47 mm, roller width: 24 mm.
Q2: What load can MCF 47 S bear?
A2: Mainly for heavy radial loads; avoid excessive axial force during operation.
Q3: What does suffix S stand for?
A3: S means sealed construction to prevent foreign matter entering the bearing interior.
Q4: Can this cam follower be relubried?
A4: Yes. It comes with lubriion port for periodic grease replenishment.
Q5: What is the limiting speed under grease lubriion?
A5: The limiting speed is 2600 r/min under proper greasing conditions.
