Specifications
Price :
USD20 - 35 / Piece
Bore Diameter (d) :
50 mm
Static Load Rating (C0) :
23.2 kN
Available Variants :
LE 210 2F (Standard) / LE 210 2F.SH (Heat Stabilized)
Brand Name :
GQZ
Weight :
0.69 kg
Material :
Gcr15 Bearing Steel
Outer Ring Width (C) :
22 mm
Sealing :
2F (Double Lip Contact Seal with Flinger)
Certifiion :
ISO 9001:2015
Dynamic Load Rating (C) :
35.1 kN
Model Number :
LE 210 2F
Delivery Time :
3-7 working days for stock, 15-25 days for production
Model :
LE 210 2F
Payment Terms :
T/T,L/C,PayPal,
Supply Ability :
50000 Pieces per Month
Outer Diameter (D) :
90 mm
Place of Origin :
China
MOQ :
10 Pieces
Inner Ring Width (B) :
51.6 mm
Packaging Details :
Industrial grade anti-rust paper wrap, export-quality corrugated carton with pallet
Locking Type :
Eccentric Locking Collar
Description
LE 210 2F Insert Ball Bearing — Spherical Outer Surface Agricultural Bearing
Product Overview

The LE 210 2F is a high-capacity insert ball bearing designed to serve as the primary shaft support in medium to large agricultural machinery. With a 50mm bore, 90mm OD, and a robust 51.6mm inner ring, it provides 35.1 kN kN of dynamic load capacity — sufficient for demanding PTO-driven and hydraulic-powered equipment.

The wide inner ring design increases shaft contact area, reducing fretting and extending service life under combined radial and axial loads. The spherical outer surface eliminates binding caused by frame flex and weld distortion in large welded assemblies.

Built for professional farmers and equipment OEMs who need bearings that perform reliably across long operating seasons with minimal maintenance.

Get a quote within 24 hours for your project.

Technical Specifiions
ModelLE 210 2F / LE 210 2F.SH (Heat Stabilized)
Inner Diameter (d)50 mm
Outer Diameter (D)90 mm
Inner Ring Width (B)51.6 mm
Outer Ring Width (C)22 mm
Eccentric Collar Width (s)19 mm
Inner Ring Shoulder (d1)62.5 mm
Eccentric Groove (E)6.4 mm
Lubriion Fitting (Gs)M10*1
Tightening Flat (sw)5 mm
Chamfer (r1.2 / r3.4)1 mm / 1.5 mm
Dynamic Load Rating (C)35.1 kN
Static Load Rating (C0)23.2 kN
Fatigue Load Limit (Pu)0.98 kN
Weight0.69 kg
Sealing2F (Double Lip Contact Seal with Flinger)
Locking TypeEccentric Locking Collar
MaterialGcr15 Bearing Steel
Available VariantsLE 210 2F (Standard) / LE 210 2F.SH (Heat Stabilized)

Full technical data and drawings available upon request.

Appliions
  • PTO-driven rotary tillers and power harrows
  • Large round balers and forage harvesters
  • Grain augers and bucket elevator head shafts
  • Slurry tanker agitators and pumps
  • Heavy-duty mower conditioners
  • Industrial mixer and blender shafts

Suitable for high continuous loads, intermittent shock loading, and extended running hours in outdoor environments.

Key Advantages
  • High 35.1 kN kN dynamic load rating handles heavy PTO-driven implement loads
  • Extended 51.6mm inner ring provides superior shaft support and alignment stability
  • Spherical outer surface (±2°) prevents edge loading even in flexing chassis frames
  • Eccentric locking collar with precision-ground eccentric provides vibration-resistant clamping
  • 2F double-lip seal with flinger protects internal raceways from chaff, soil, and water ingress
  • Micro-finished raceways (Ra 0.1 μm) reduce friction and operating temperature
  • Factory pre-lubried with EP2 grease for immediate field deployment
  • Available in standard (2F) and heat-stabilized (2F.SH) variants for demanding environments

Premium performance for the equipment that drives modern agricultural productivity.

Why Choose GQZ Bearing
  • 25+ years experience in industrial bearing manufacturing and export
  • Exported to 50+ countries worldwide with reliable logistics
  • Rich experience in OEM and custom bearing projects
  • 100% quality inspection with precision CNC machining and strict heat treatment control
  • Fast response within 24 hours for all inquiries
  • Stable supply capacity for long-term cooperation

We focus on quality, reliability, and long-term partnership with every customer.

LE 210 2F High-Capacity Insert Ball Bearing 50mm Bore 90mm OD for Agricultural Equipment

LE 210 2F High-Capacity Insert Ball Bearing 50mm Bore 90mm OD for Agricultural Equipment

LE 210 2F High-Capacity Insert Ball Bearing 50mm Bore 90mm OD for Agricultural Equipment

LE 210 2F High-Capacity Insert Ball Bearing 50mm Bore 90mm OD for Agricultural Equipment

Get a Quote Now

Looking for a reliable agricultural bearing supplier?

Send your inquiry to get:

  • Fast quotation within 24 hours
  • Technical support from experienced engineers
  • Custom solution suggestions for your appliion
  • Competitive factory-direct pricing

Click Send Inquiry or contact us now to discuss your bearing requirements.

FAQ

Q1: Can you provide custom bearings?

Yes, we support OEM and custom production based on your drawings, samples, or technical requirements.

Q2: What is the delivery time?

Standard models: 7–15 working days. Custom products: depending on specifiions and order quantity.

Q3: Do you provide samples?

Yes, sample orders are welcome for quality evaluation before bulk purchase.

Q4: What is the difference between 2F and 2F.SH?

2F is the standard version suitable for operating temperatures -20°C to +100°C. 2F.SH is the heat-stabilized version for appliions up to +150°C.
