All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit
Specifications
Payment Terms :
T/T,,PayPal
Housing Type :
Split Plummer Block
Net Weight :
13.7 kg
MOQ :
1 Piece
Price :
$20-$50
Shaft Diameter :
80 mm
Supply Ability :
3000 Pieces per Month
Lubriion :
Grease / Oil
Certifiion :
ISO 9001
Packaging Details :
Packed in carton firstly, then reinforced with wooden case for outer packing
Adapter Sleeve :
H2318
Delivery Time :
3-7 working days after payment
Model Number :
LKS 218 2F + H2318
Brand Name :
GQZ
Product Name :
LKS 218 2F + H2318
Dimensions :
80x327x200.0mm
Place of Origin :
China
Housing Material :
Cast Iron
Description
LKS 218 2F + H2318 Heavy Duty Plummer Block Bearing Housing 80mm Shaft Diameter

The LKS 218 2F + H2318 is a high-performance complete plummer block housing kit with taper adapter sleeve designed for industrial bearing appliions. It accommodates spherical roller bearings and self-aligning ball bearings with a 80mm shaft diameter, providing excellent support and alignment for rotating shafts in demanding environments.

Product Features
  • Split housing design for easy bearing installation and maintenance
  • Made of high-strength cast iron for exceptional durability and load capacity
  • Precision machined bore with included taper adapter sleeve ensures accurate bearing seating and alignment
  • Suitable for both oil and grease lubriion systems
  • Ribbed housing design enhances heat dissipation and structural rigidity
  • Includes matching H-series taper adapter sleeve and lock nut for quick bearing mounting
Technical Specifiions
Parameter Value
Model LKS 218 2F + H2318
Shaft Diameter (d) 80 mm
Overall Length (L) 292 mm
Width (A) 78 mm
Height (H) 175 mm
Center Height (H₁) 88.9 mm
Base Height (H₂) 30 mm
Mounting Span Min (Jmin) 222 mm
Mounting Span Max (Jmax) 242 mm
Bolt Hole Width (N) 25 mm
Bolt Hole Length (N₁) 35 mm
Seal Width (S₁) 47.6
Net Weight 9.2 kg
Material Cast Iron
Housing Type Split Plummer Block
Appliions
  • Conveyor systems and material handling equipment
  • Fans, blowers, and air handling units
  • Crushers and mining machinery
  • Pumps and compressors
  • Industrial gearboxes and transmission systems
Why Choose GQZ
  • 25+ years experience in industrial bearing manufacturing
  • Exported to 50+ countries worldwide
  • Rich experience in OEM & custom projects
  • Strict quality inspection before shipment
  • Fast response within 24 hours
  • Stable supply for long-term cooperation

All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit

All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit

All-In-One SN Housing Sleeve Kit LKS 218 2F H2318 80mm Shaft Cast Iron Plummer Block Base Unit

FAQ

Q1: Do you support custom or non-standard dimensions?

Yes, we offer OEM service and can produce housings according to your drawings or samples. Contact us with your specifiions for a custom quote.

Q2: What is your MOQ and delivery time?

Our minimum order quantity is 1 piece for standard models. Delivery time is 3-7 working days for stock items, and 15-30 days for production orders depending on quantity.

Q3: How do you ensure quality?

All housings undergo dimensional inspection, material testing, and surface finish checks before shipment. We are ISO 9001 certified and provide material certifies upon request.
