Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit
Specifications
MOQ :
1 Piece
Shaft Diameter :
55 mm
Lubriion :
Grease / Oil
Delivery Time :
3-7 working days after payment
Adapter Sleeve :
H2312
Payment Terms :
T/T,,PayPal
Housing Type :
Split Plummer Block
Certifiion :
ISO 9001
Net Weight :
4.55 kg
Place of Origin :
China
Model Number :
LKS 212 2F + H2312
Supply Ability :
3000 Pieces per Month
Product Name :
LKS 212 2F + H2312
Price :
USD 25-50 / Piece
Dimensions :
55x241x136.8mm
Brand Name :
GQZ
Packaging Details :
Packed in carton firstly, then reinforced with wooden case for outer packing
Housing Material :
Cast Iron
Description
LKS 212 2F + H2312 Heavy Duty Plummer Block Bearing Housing 55mm Shaft Diameter

The LKS 212 2F + H2312 is a high-performance complete plummer block housing kit with taper adapter sleeve designed for industrial bearing appliions. It accommodates spherical roller bearings and self-aligning ball bearings with a 55mm shaft diameter, providing excellent support and alignment for rotating shafts in demanding environments.

Product Features
  • Split housing design for easy bearing installation and maintenance
  • Made of high-strength cast iron for exceptional durability and load capacity
  • Precision machined bore with included taper adapter sleeve ensures accurate bearing seating and alignment
  • Suitable for both oil and grease lubriion systems
  • Ribbed housing design enhances heat dissipation and structural rigidity
  • Includes matching H-series taper adapter sleeve and lock nut for quick bearing mounting
Technical Specifiions
Parameter Value
Model LKS 212 2F + H2312
Shaft Diameter (d) 55 mm
Overall Length (L) 219 mm
Width (A) 60 mm
Height (H) 125.5 mm
Center Height (H₁) 63.5 mm
Base Height (H₂) 24 mm
Mounting Span Min (Jmin) 163 mm
Mounting Span Max (Jmax) 180 mm
Bolt Hole Width (N) 20 mm
Bolt Hole Length (N₁) 27.5 mm
Seal Width (S₁) 33.4
Net Weight 3.62 kg
Material Cast Iron
Housing Type Split Plummer Block
Appliions
  • Conveyor systems and material handling equipment
  • Fans, blowers, and air handling units
  • Crushers and mining machinery
  • Pumps and compressors
  • Industrial gearboxes and transmission systems
Why Choose GQZ
  • 25+ years experience in industrial bearing manufacturing
  • Exported to 50+ countries worldwide
  • Rich experience in OEM & custom projects
  • Strict quality inspection before shipment
  • Fast response within 24 hours
  • Stable supply for long-term cooperation

Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit

Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit

Plug-Play SN Plummer Assembly LKS 212 2F H2312 55mm Shaft Cast Iron Split Bearing Housing Kit

FAQ

Q1: Do you support custom or non-standard dimensions?

Yes, we offer OEM service and can produce housings according to your drawings or samples. Contact us with your specifiions for a custom quote.

Q2: What is your MOQ and delivery time?

Our minimum order quantity is 1 piece for standard models. Delivery time is 3-7 working days for stock items, and 15-30 days for production orders depending on quantity.

Q3: How do you ensure quality?

All housings undergo dimensional inspection, material testing, and surface finish checks before shipment. We are ISO 9001 certified and provide material certifies upon request.
