Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Specifications
Brand Name :
Optional
Model Number :
RPNA15 / 28
Certification :
ISO9000/QS9000
Place of Origin :
GERMANY
MOQ :
1.PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000.pcs / Month
Delivery Time :
Within 3 days
Packaging Details :
Standard Carton Box
Size :
15x28x12mm
Structure :
Aligning Needle Roller
Inner Ring :
Without Inner Ring
Type :
Insert Bearing
Weight :
0.03KG
Limiting Speed :
24100
Cage :
Sheet Steel
Stock :
165.pcs
Description

Insert Bearing RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm

Stock QTY : 165.pcs (More on the way)

Size : 15x28x12mm Weight : 0.03KG

Bearing Model

PNA 15 / 28

Structure

Aligning Needle Roller Bearing

Size (dxDxB) mm

15x28x12mm

d (mm)

15

D (mm)

28

B (mm)

12

Weight /Mass (KG)

0.04

Contact Person

Tommy

SKYPE

gqbearing
WhatsApp/ Webchat +8618261541498

E-mail

tommy@gqbearing.com

We currently have 165.pcs of PNA15 / 28 High Load Aligning Needle Roller Bearing In Stock.If you are in need of PNA15/28 Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.

For more details of PNA 15 / 28 ,please feel free to contact me by WhatsApp or SKYPE or E-mail.

Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the " Contact Now "button for Price & other Information.

Bearing Model d (mm) D (mm) B (mm)
PNA12/28 12 28 12
PNA15/32 15 32 16
PNA17/35 17 35 16
PNA20/42 20 42 20
PNA22/44 22 44 20
PNA25/47 25 47 20
PNA30/52 30 52 20
PNA35/55 35 55 20
PNA40/62 40 62 20
RPNA15/28 15 28 12
RPNA18/32 18 32 16
RPNA20/35 20 35 16
RPNA25/42 25 42 20
RPNA28/44 28 44 20
RPNA30/47 30 47 20
RPNA35/52 35 52 20
RPNA40/55 40 55 20
RPNA45/62 45 62 20


Aligning needle roller bearings are X-life bearings. These bearings have optimised raceway surfaces. This gives higher load carrying capacity and longer rating life.

Bearings without inner ring have particularly compact radial dimensions. However, they require a shaft raceway that is hardened and ground.

Compensation of Misalignments : Due to the Spherical Outer Ring and the concave support ring, aligning bearings can compensate static misalignments between the shaft and housing of up to 3°.

Sealing : Aligning needle roller bearings are not sealed.

Lubrication : The open bearings can be lubricated with oil or grease.

Operating temperature : The range of possible operating temperatures is from –20 °C to +100 °C,

restricted by the plastic support rings.

Cages : The cages are made from sheet steel.

Insert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mmInsert Type RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
