Waste Plastic Shredder Machine For Sale Scrap Tire Shredding Machine Industrial Double Shaft Shredder Heavy Duty Plastic Metal Waste Recycling Machine Plastics Recycling Machine
Shredders are generally used to shred plastics, rubbers, large tires, large nylon materials, rubber head materials, car bumpers, large pieces of fish nets, large pipes, fibers, paper, wood, electrical components, cables, PET bottles, cardboard, circuit boards, wood, plastic barrels and other solid objects that are difficult to shred. Shredders are also called scrap metal shredders, double-shaft shredders, wood shredders, tire shredders, plastic shredders, pipe shredders, garbage shredders, circuit board shredders, rubber shredders, aluminum shredders, etc. The main function of this equipment is to squeeze large pieces of materials and large-diameter barrel metal materials that are inconvenient to transport into sheet materials that meet the requirements through the shearing of the shredder. Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com
Advantages of double-shaft shredder Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com
1. Double-shaft mechanism, using multiple multi-claw cutters, and cooperating with the cutter shaft for multi-angle changes, saving effort during cutting and strong cutting force. 2. The motor is driven by the gearbox transmission system to make it a low-speed and high-torque powerful operation to achieve a crushing effect.
3. The large transmission wheel is made of special steel, hardened by heat treatment, and has a long service life. Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com
4. The gearbox adopts an oil-intake pulley, which runs smoothly, has low noise, high torque, and can operate for a long time.
5. The design of low speed and high torque provides lower noise and less dust, and improves a good working environment.
| Model | pw-400 | pw-600 | pw-800 | pw-1000 | pw-1200 |
| Blade diameter(mm) | 200 | 255 | 300 | 300 | 400 |
| Blade thickness(mm) | 20 | 20 | 20(40) | 40(50) | 50(60) |
| Blade number | 20pcs | 30pcs | 40(20)pcs | 25(20) | 24(20) |
| Blade material | 55CrSi | 55CrSi | 55CrSi | 55CrSi | 55CrSi |
| Capacity | 350kg/h | 800kg/h | 1500kg/h | 3000kg/h | 4000-5000kg/h |
| Blade box size(mm) | 400*400 | 600*600 | 800*600 | 1000*800 | 1200*1000 |
| Power(kw) | 11*2 | 15*2 | 22*2 | 30(37)*2 | 45(55)*2 |
| Rducer model | 400model*2 | 400model *2 | 500model *2 | 650model*2 | 750model*2 |
| | | | | | Rotational Speed(r/min) | |
| 600M | Φ200*10 | 15kw | 48 | 400 | 18-25 | 1.45*0.87*2.2 |
| 600M | Φ200*20 | 15kw | 24 | 400 | 18-25 | 1.45*0.87*2.2 |
| 800M | Φ200*20 | 15kw*2 | 32 | 400*2 | 18-25 | 2.15*0.87*2.2 |
| 800M | Φ300*30 | 30kw*2 | 18 | 650*2 | 18-25 | 3.4*1.2*2.2 |
| 1000M | Φ300*25 | 30kw*2 | 32 | 650*2 | 18-25 | 3.4*1.25*2.2 |
| 1000M | Φ300*30 | 30kw*2 | 27 | 650*2 | 18-25 | 3.4*1.25*2.2 |
| 1000M | Φ400*40 | 45kw*2 | 20 | 750*2 | 18-25 | 3.4*1.25*2.2 |
| 1200M | Φ400*30 | 55kw*2 | 38 | 650*2 | 18-25 | 4.15*1.25*2.2 |
| 1200M | Φ400*40 | 55kw*2 | 28 | 750*2 | 18-25 | 4.15*1,25*2.2 |
| 1500M | Φ400*30 | 75kw*2 | 48 | 750*2 | 18-25 | 4.15*1.25*2.2 |
| 1500M | Φ400*40 | 75kw*2 | 36 | 750*2 | 18-25 | 4.15*1.25*2.2 |
| 1500M | Φ400*50 | 75kw*2 | 28 | 850*2 | 18-25 | 4.15*1.25*2.2 |
| 2000M | Φ530*50 | 90kw*2 | 38 | 850*2 | 18-30 | 5.25*1.78*2.2 |
| 2000M | Φ600*60 | 90kw*2 | 31 | 850*2 | 18-30 | 5.25*1.78*2.2 |
Brief Description of Dual-Shaft Shredder:
1. Core Definition: A dual-shaft counter-rotating shear shredder, achieving material cutting, tearing and volume reduction with low speed and high torque. Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com
2. Application Scope: Processes over 100 types of materials (metal, plastic, rubber, wood, home appliances, waste, etc.),
suitable for large/bulky hard-to-shred materials like scrap steel, tires, drums, and construction formwork.
3. Core Value: Key equipment for industrial solid waste resource pretreatment, with 70%-90% volume reduction rate. Shredded materials can be directly recycled or connected to downstream processing, supporting circular economy.
Key Features of Dual-Shaft Shredder
1. High Efficiency & Stability: Dual-shaft meshing design, 30% more efficient than single-shaft models. Uniform discharge with adjustable particle size (3-120mm), no shaft wrapping or jamming.
2. Durability: Special alloy steel blades + thickened welded frame, wear-resistant and impact-resistant. Blades can be
re-sharpened for long service life.
3. Safety & Low Consumption: Low-speed operation (7.5-50r/min), noise ≤75dB, low dust. Equipped with PLC intelligent overload protection and reverse function. Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com
4. Easy Maintenance: Modular cabinet + split bearing seat design, enabling quick blade replacement and component inspection, reducing maintenance costs by 40%.
5. Flexible Adaptability: Supports manual/conveyor automatic feeding, power range 7.5kw-315kw. Customizable models for 0.2-100t/h capacity requirements. Please inquiry us:
Whatsapp: +8613780964661 Bagplastics@Gmail.com



Series Twin-Shaft Shredder
( plastic, paper, fiber, rubber, organic waste)
The GL series shredders have been designed for a wide array of applications and industries,suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires,packaging barrel, pallets, etc. Depending on input material and the following process theshredded material can be used directly or go into the next step of size reduction. lt is widelyused in industry waste recycling, medical recycling, electronic recycling, pallet recycling,municipal solid waste recycling, Bagplastic.com plastic recycling, tire recycling, papermaking industry and etc.
● WORKING PRINCIPLE--------------------------------------------------------- The twin-shaft shredder mainly rotates relative to each other through two knife rollers. The cutting edge is formed between the cutting edge and the cutting edge. At the same time, the knife hook tears the material, so as to achieve the effect of crushing the knife. Bagplastic.com Its structure is mainly composed of shredding blade group, bearing box, box support, feeding system and power system. The discharge size can be adjusted according to the user's requirements. In the application process of double shaft crusher, the knife speed is low, which ensures no harm to safety, low noise, low energy consumption and strong usefulness
PRODUCT PARAMETERS(partially)-----------------------------------------------------------------------
| Model number | GL600 | GL 800 | GL 1000 | GL 1200 | GL 1300 | GL 1600 |
| Main motor power | 11+11 | | 22+22 | 30+30 | 37+37 | 55+55 |
| Rotor-blade | 20 | 16 | 20 | 24 | 26 | 32 |
| Whight /kg | 2200 | 2400 | 5400 | 7000 | 12000 | 14100 |
| Rotor diameter(mm) | 340 | 340 | 340 | 340 | 400 | 400 |
| Main shaft speed | 15 r/min | 14 r/min | 15r/min | 15 r/min | 14 r/min | 11 r/min |
PRODUCT DETAILS--------------------------------------------------------------------------------
Single shaft shredder: mainly for
die head extrusion block shredding,HDPE pipe shredding,profile shredding,film shredding
Double shaft shredder: mainly for tires shredding,film shredding,profile shredding,barrel shreding,tray shredding
Double single shaft shredder: mainly for film shredding with big capacity
Four shaft shredder: mainly for tires shredding,tray shredding
| Model | Feeding mouth size | Motor power | Rotate blade | Fix blade |
| WT600 | 630*800mm | 30kw | 39 | 2 |
| WT800 | 830*900mm | 45kw | 57 | 2 |
| WT1000 | 1030*1200mm | 55kw | 63 | 2 |
| WT1200 | 1230*1400mm | 75kw | 75 | 2 |
Blades
The blades are divided into fixed and dynamic knives, Bagplastic.com which can be removed and replaced.
According to different materials, the thickness and hooks of blades can be customized.
The GL series double-shaft shredder can be generally used to shred more difficult to crush plastic, rubber, fiber, paper, wood, electrical parts, cables and other solid materials, such as: water mouth material, rubber head, Bagplastic.com PET bottles, cardboard, circuit boards, wood, plastic barrels, etc..Clients can choose the appropriate model according to the size of the material and the processing capacity. If users need to crush especially hard materials, they need to explain the situation.
●ATTENTION-------------------------------------------------------------------------
Install the blade correctly
If the blade is installed too loosely or too tightly, the blade of the shredder can not crush materials normally, which will aggravate the damage to the blade in the long term.
Reduce crushing of wetter materials Bagplastic.com When too wet materials are crushed, due to excessive extrusion, it is easy to squeeze out the water in the materials and stick to the blade of the shredder, which is easy to rust the blade.
Blade screw tightening If the screw of the machine is too loose, the blade will slip during crushing, and the crushing effect cannot be achieved.
Choose different shredders according to different materials Do not put too hard materials in the shredding chamber of the shredder. Too hard materials are easy to wear the blade. Often tear some hard materials, which will directly damage the blade of the shredder and can not crush other materials.



Plastic crusher is specialized in crushing various kinds of plastic materials into different sizes of granules. Crushed plastics can be recycled for the reproduction of plastic products. This machine can help reduce Bagplastic.com the volume of plastic waste, greatly save costs and resources.
waste plastic pipe/profile and others product recycled crusher machine
PLastic recycling crusher machine/rigid plastic grinder machine/ plastic bottle grinding /shredder machine /plastic shredding
crushing recycled PLEASE INQUIRY US
BAGPLASTICS@GMAIL.COM WHATSAPP:+8613780964661
1) Suitable for recycle of all kinds of plastic bottles, Bagplastic.com containers, pellicle, plastics sheets,spurs from injection molding machines and extrustion parts.
2) Strong structure, easy to operate, low electricity consumption & durable.
3) Uses high quality steel material especially for making knives of the crushers, the machine stands long use under severe and continuous service conditions.
4) The blades can be grinded for many times and can be used repeatedly.
5) Blades base is made of high quality steel, hard to be broken and damaged; Blades base structure is stable and durable.
PC series plastic crusher absorbs domestic and foreign advanced technology; it has the rational design and repeated tests and keeps improving. PLEASE INQUIRY US
BAGPLASTICS@GMAIL.COM WHATSAPP:+8613780964661
The machine has some features such as light in weight, low energy consumption, good quality, long life and easy to clean. PC series plastic crusher is suitable for smashing polystyrene, polypropylene, nylon, defective plastic products of injecting and extruding machine. If you change the suitable sieve and adjust the space among the blades, it can also be used in smashing the waste of various plastic such as PVC/PP/PE films, PET bottle , Bagplastic.com plastic sheet , ABS, EVA and so on.
This machine is suitable for crush many kind of plastic products like plastic blocks, plastic sheet, plastic injection waste materials and plastic film
Here are some advantages of this machine.
The first one is Low energy consumption, easy to install, operate and maintain
The second one is Change the different diameter sieve, can get different size of final scrap.
The third one is Machine automatic stop when the cutting blades are exposed.
The fourth on is there is a dust curtain fitted at the feed hopper.
PLEASE INQUIRY US
BAGPLASTICS@GMAIL.COM WHATSAPP:+8613780964661
| MODEL | MOTOR POWER | | ROTARY BLADE | CAPACITY |
| PC400 | 7.5 | 2 | 6/12 | 80-250kg/h |
| PC500 | 11/15 | 2 | 6/15 | 120-320 kg/h |
| PC600 | 18.5/22 | 2 | 6/18 | 180-400 kg/h |
| PC800 | 37/55 | 2/4 | 6/24 | 400-800 kg/h |
| PC1000 | 45/55 | 4 | 6/30 | 800-1200 kg/h |
| PC1200 | 75/110 | 4 | 6/34 | 800-1500 kg/h |

| 1 | Model | PC1000 |
| 2 | Input size for plastic crusher | 1000x580mm |
| 3 | Rotation diameter | 580mm |
| 4 | Motor power | 45kw |
| 5 | Qty of rotary blade | 10pcs |
| 6 | Qty of fixed blade | 4pcs |
| 7 | | SKD11 (good material, with long life) |
| 8 | Screen net for plastic crusher | 10mm |
| 9 | Dimension of the main | 2000x1480x2300 |
| 10 | Weight | 2200kg |


Why choose us? 1.Low cost All the machine ,we make by ourselves to reduce the cost for our customers.
2.Genuine product with excellent quality We choose our material very strict. All the material come to our factory must pass the quality test Substandard goods are returned to the supplier.
3. Engerneers available to serve oversea PLEASE INQUIRY US
BAGPLASTICS@GMAIL.COM WHATSAPP:+8613780964661
4.Quick delivery The company provide just in time delivery with its streamlined supply chain.
5.Cost saving We take strong attention to every detail in the manufacturing process. The quality control in our factory is very strict. All defective semi-manufactures must be treated again or rejected. All the machine must be checked before delivering to our customer. What we want to do is to give our customer a good quality product with stable and long time working life.
PLEASE INQUIRY US
BAGPLASTICS@GMAIL.COM WHATSAPP:+8613780964661
