Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Automatic Auger Filling Machine / 50g To 5000g Auger Powder Filler
Specifications
Brand Name :
Hefei Leadall
Model Number :
LA-B22
Certification :
CE ISO
Place of Origin :
Hefei , China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
50 Sets Per Month
Delivery Time :
10 to 20 work days
Packaging Details :
Standard Wooden Case for Export
Filling Weight :
50-5000g
Filled Error :
±0.2-1%
Power Supply :
2Kw, 380V 50Hz/60Hz
Filling Speed :
15-30bottles(cans)/min
Hopper Volume :
50L
Overall Dimensions :
2400mm*1200mm*2400mm
Application :
Food,Medical
Automatic grade :
Automatic
Driven type :
Electric,Pneumatic
Packaging type :
Bottles,Cans
Description

50g To 5000g Automatic Auger Filling Machine / Auger Fillers For Filling Food Powder

Product profile:

This automatic powder filling machine, it is suitable for packing powder and granular materials, such as: milk powder, feed powder, rice powder, coffee powder, monosodium glutamate, solid drink, glucose, solid medicine, etc.

Descriptive abstract:

This type can do measuring and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like condiment, cosmetic, coffee powder, solid drink, pharmaceuticals, agriculture pesticide, granular additive, dyestuff, and so on.

Product usage:

This machine is suitable for many kinds of powder such as:

Milk powder, flour, rice powder, protein powder, Seasoning powder, chemical powder, medicine powder, coffee powder, soy flour etc.

Product feature:

1 The whole machine is made of stainless steel
2 Chinese/English is displayed in touch screen
3 The machine is designed in term of National "QS" and "GMP"
4 The combination of whole sealed, stainless steel and plexiglass box, can open by sideway, make the clean easily
5 You may store 10 kinds of working parameters in the machine
6 For the dusty material, we can add a vacuum device to keep the workplace clean
7 The machine suitable for lot kinds of package size and powdery material through changing the auger attachment
8 Servo motor drive screw, got high accuracy
9 This machine we add weighing system, can got better accuracy

Technological parameters:

Model LA-B22
Metering Mode weighing mode(gross weight)
Package Weight 50-5000g changeable( by changing auger attachment)
Package Accuracy ±0.2-1%(according to the material )
Packaging Speed 15-30bottles(cans)/min
Hopper Volume 50L
Power Supply 380V/220V 50Hz/60Hz
Atmospheric pressure and Use Tolerance 6Kg/cm2;0.2m3/min
Total Power 2Kw
Overall Dimensions 2400mm*1200mm*2400mm
Operational Style PLC control system, 5.7 inch colorful touch screen

Optional devices:

1 Leak-proof centrifugal device (for small granule)
2 Dust collecting cover
3 Level Split hopper
4 Lift-fall device

Relevant supporting equipment:

1 VFFS Packaging Machine line
2 Multihead weigher, Linear weigher, Auger filler, Counting machine
3 Automatic vacuum packing machine line
4 Automatic secondary packing machine(put small bags into large bags)
5 5-50kg Automatic bag feeding packing machine
6 Check weigher, Metal detector, Conveyor, Elevator
7 Automatic carton case packing line
8 Robot Palletizing Line

Normally we have some questions to customers:

1 What is your packing product?
2 How many grams per bag?
3 What is your bag size(the width and length)?
4 What is voltage and Hertz in your local?
5 If you want to design the special packing machine, we can manufacture the packing machine as your requirements.
