Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Specifications
video outgoing-inspection :
Not Available
machinery test report :
Not Available
core components :
bag filter housing
Place of Origin :
China
Brand Name :
YATE
warranty :
1 Year
productivity :
others
weight (kg) :
185
Processing Type :
Filtration
Product name :
Stainless Steel Cartridge filter housing
Application :
Water Treatment
Type :
multiple cartridge
Material :
Stainless Steel 304
Usage :
Liquild Filter
Size :
Customized Size
Name :
water cartridge filter
Working Pressure :
0.6Mpa
Filter Material :
PP/PE
Min. Filtration Precision :
0.5 μm
MOQ :
1
Price :
$500
Description

APPLICATION OF STAINLESS STEEL CARTRIDGE FILTER

Cartridge filters are suitable for liquid precision filtering to remove tiny impurities and bacterium, and are widely used in the following industries.
* Oil & gas. Produced water filtration; injection water filtration; completion fluid filtration; natural gas extraction; amine sweetening; desiccant dehydration;
* Metallurgy. Hydraulic and lubrication system filtration;
* Machining. Machine tool coolant circulating filtration;
* Food & beverage. Fermented beer filtration, beer final filtration, wine filtration, bottled water filtration, soft drink filtration, juice filtration, dairy filtration;
* Water treatment. household drinking water filtration, domestic wastewater filtration;
Ultra-pure water filtration
* Marine filtration system. Seawater desalination.
Contact: Shirley Ju
Email: yate20201225@163.com
Whatsapp/WeChat/Mob.: + 8615265667398
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Products Description
Large Flow 0.22 Micron Pleated Filter Stainless Steel Cartridge Filter Housing with 0.6Mpa Working Pressure
Model
Filter cartridge
cartridge
Qty
Connection
Max.Flow
(m3/h)
Working Pressure(MPa)
YT-1D
40”
1
DN50
40
0.6
YT-2C40N
40”
2
DN50-DN100
80
0.6
YT-3C40N
40”
3
DN80-DN100
120
0.6
YT-4C40N
40”
4
DN80-DN100
160
0.6
YT-5C40N
40”
5
DN80-DN100
200
0.6
YT-6C40N
40”
6
DN80-DN100
240
0.6
YT-7C40N
40”
7
DN80-DN100
280
0.6
YT-8C40N
40”
8
DN100-DN200
320
0.6
YT-10C40N
40”
10
DN150-DN200
400
0.6
YT-12C40N
40”
12
DN150-DN250
480
0.6
YT-14C40N
40”
14
DN200-DN250
560
0.6
YT-16C40N
40”
16
DN200-DN300
640
0.6
YT-18C40N
40”
18
DN250-DN350
720
0.6
YT-20C40N
40”
20
DN250-DN400
800
0.6
YT-22C40N
40”
22
DN300-DN450
880
0.6
YT-24C40N
40”
24
DN350-DN450
960
0.6
