5 Button Sound Board with Custom Voice ABS Material CE & Rohs Certified Sound Module for Children's Books
5 Button Sound Board with Custom Voice ABS Material CE & Rohs Certified Sound Module for Children's Books
Specifications
Certification :
CE, EN71
MOQ :
3,000 Pieces
Price :
US $0.86-1.18 / Pie
Module size :
188*45*13.5mm
Battery type :
AG13 *3PCS
Operating voltage :
4.5V
Battery life :
500~560 cycles
Storage time :
2-3 years
Sound duration :
3~5 seconds per button
Total duration :
20 seconds
Speaker size :
27mm
Speaker impedance :
16Ω
Volume range :
75-85 dB
Material :
ABS + art paper
Sticker paper :
157GSM art paper
Front cover size :
191*193mm
Back cover size :
191*242mm
Paper weight :
400gsm CCNB
Description
5 Button Sound Board, Sound Pad, Sound Module for Children's Sound Book
Professional 5-button sound board and sound module designed specifically for children's interactive sound books. This complete solution includes both the printed book and electronic sound module components.
Book Specifications
  • Materials: Front Cover: 191×193mm, Back Cover: 191×242mm, 400gsm CCNB
  • Printing: 4-color process printing with UV varnishing
  • Extent: 5 spreads + cover
  • Binding: Custom shaped board book with rounded corners
  • Features: No battery case die cut on back cover
Sound Module Specifications
  • Module Size: 188×45×13.5mm (custom molds available)
  • Sticker: 157GSM art paper × 1 piece
  • Batteries: 3 × AG13 batteries, 4.5V operating voltage
  • Battery Life: 500-560 cycles, 2-3 years storage time
  • Sound Options: Standard sounds or custom voices including animal sounds, transportation sounds, melodies, and human speech
  • Volume: 75-85 dB (meets children's book standards)
  • Speaker: 27mm × 1 piece
  • Materials: Non-toxic, environmentally-friendly, compliant with CE/ROHS/EMC/EN71-3 standards
  • Testing: SGS testing reports available for all raw materials
  • Sample Time: 7 working days after receiving custom sound & sticker
5 Button Sound Module Technical Details
Item 5 Button Sound Module
Material ABS + art paper
Specification 188×45×13.5mm, AG13 × 3PCS, 1pc 157gsm art paper, 4C 1pc 29mm speaker, 16Ω
IC Duration 3-5 seconds per button, 20 seconds total (customizable based on sound files)
Operation Each button activates one sound
Payment Terms T/T, 30% deposit + 70% balance before shipment
Production Time 30-45 days after sample approval
Package Customized packaging according to requirements
Product Images
5 Button Sound Board with Custom Voice ABS Material CE & Rohs Certified Sound Module for Children's Books 5 Button Sound Board with Custom Voice ABS Material CE & Rohs Certified Sound Module for Children's Books
Our Services
  • Quotation provided within 2 working days
  • Excellent design services according to customer requirements
  • Sample charge refunded when placing an order
  • OEM Manufacturer - custom shapes, designs, and sounds welcome
  • Professional technical team to solve all technical problems
  • Strict quality checking before shipping
Quality Concerns: Please contact us at (86)0755-28791270 for any quality problems.
