HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
Specifications
Brand Name :
Waylead
Model Number :
WZ-220
Certification :
/
Place of Origin :
Shanghai
MOQ :
1
Price :
Negotiations
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
300 sets per year
Delivery Time :
20
Packaging Details :
International standard packaging for shipping
Package Length :
120-300 mm
Package Width :
35-80 mm
Packing Speed :
30-150 bags/min
Packing Film type :
PP、PVC、PS、EVA、PET、PVDC+PVC、OPP+(RECOMBINATION)CPP
Type of power supply :
220V 50HZ
General power :
(L)4020mm(W)800mm (H)1450mm
Weight :
3.1 KW
Dimension :
4000x 930x1370 mm
Description
Frequency Conversion Control Flow Wrapping Machine Moisture-Proof Sealing Packaging
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
HFFS Horizontal Flow Wrapping Machine
Working Principle and Operational Technical Guide

Fundamental Operating Principle

Film Transport Mechanism

Upon unwinding the roll film through the guide roller, the servo drive system precisely moves it, guaranteeing a tension control precision of ±0.5.

A photoelectric sensor monitors the color mark, automatically correcting any stretching errors in the printed material with an accuracy of ±0.3mm.

Formation and Filling Stage

The former molds the film to form a cylindrical structure for housing the product.

A synchronized conveyor gently ushers the product into the film cylinder with a speed deviation of under 1%.

Heat Sealing and Cutting Unit

The vertical sealing device maintains a consistent temperature (adjustable within the range of 150 to 200℃) to ensure a sealing strength of ≥4N/15mm.

The horizontal sealing cutter is equipped with dual temperature and pressure adjustments, facilitating simultaneous cutting and end sealing.

Technical Specifications
Model WZ-220(single jaw) WZ-220(double jaws) WZ-220(triple jaws)
Package Length 120-300 mm 60~200 mm 45~100mm
Package Width 35-80 mm 35-80 mm 35-70 mm
Package Height 5-35 mm 5-35 mm 5-30 mm
Packing Speed 30-150 bags/min 30-250 bags/min 30-450 bags/min
Package Height 90-220 mm 90-220 mm 90-220 mm
Packing Film type PP,PVC,PS,EVA,PET,PVDC+PVC,OPP+(RECOMBINATION)CPP
Type of power supply 220V 50HZ 220v 50HZ 220v 50HZ
General power 3.1 KW 3.8 KW 4.5 KW
Weight 360 Kg 360 Kg 360 Kg
Dimension 4000x 930x1370 mm
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
Product Application

The HFFS horizontal flow wrapping machine serves diverse industries with its versatile packaging capabilities:

  • Food packaging: Candies, biscuits, chocolates, pastries, frozen foods and quick-frozen foods
  • Medical product packaging: Medicines, health products, medical devices and medical consumables
  • Cosmetic packaging: Facial masks, lotions, shampoos, shower gels and other cosmetic products
  • Daily necessities packaging: Detergents, shampoos, shower gels, soaps, and personal care products
  • Agricultural product packaging: Seeds, fertilizers, pesticides with moisture-proof protection
  • Electronic product packaging: Electronic components, accessories and small electronic devices
Product Advantages
  • Productivity Enhancement: High-speed packaging capability meets high-volume manufacturing demands
  • Versatility: Adjustable packaging solutions for products of various shapes and sizes
  • Aesthetic Packaging: Delivers tidy and visually appealing packaging results
  • Freshness Preservation: Flow wrapping technique maintains product quality and extends shelf life
  • Resource Efficiency: Optimizes material utilization, reducing waste and packaging costs
  • User-Centric Interface: Intuitive controls simplify operation and maintenance
  • Automation Integration: Streamlines operations, reduces manual involvement and ensures consistency
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
Selection Considerations

When selecting an HFFS wrapping machine, evaluate these key factors:

  • Product Characteristics: Ensure compatibility with your specific product type
  • Production Capacity: Match machine capabilities with your output requirements
  • Packaging Dimensions: Verify adjustable range meets your packaging size needs
  • Automation Level: Consider the balance between automation features and cost
  • Brand Reputation and Quality: Research manufacturer reliability and machine durability
  • Budget Considerations: Balance initial investment with long-term operational benefits
HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
Our Packaging Machine Range
  • VFFS machines: Granule, powder, and liquid packing machines
  • Flow wrapping machines: Up paper, down paper, four side sealing flow, cookie/cake/popsicle packing machines
  • Heat Shrink Packaging Machine
  • Pouch packing machines: Granule, powder, liquid doypack machines, rotary and horizontal premade pouch machines
  • Automatic packaging line solutions
  • Supporting equipment: Weight inspection, metal detection, carton packing/sealing, coding, and palletizing systems

Our machines package various foods including nuts, dried fruits, bakery products, candies, frozen snacks, chocolate, chips, noodles, and more.

HFFS Horizontal Flow Wrapping Machine 30-150 Bags/Min 220V 50HZ
Frequently Asked Questions
Q1: Are you a trading company or a manufacturer?

A1: We are a manufacturer, we provide quality products at factory price, welcome to visit us!

Q2: What quality guarantee or warranty do you provide?

A2: We provide 3-year warranty and lifetime technical support.

Q3: When can I get the machine after payment?

A3: Delivery time depends on the specific machine model ordered.

Q4: How do you provide technical support?

A4: 24/7 support via phone, email or online platforms; installation guides/videos; overseas engineer services available.

Q5: How does your after-sales service work?

A5: Machines are pre-adjusted before shipment; free factory training available; lifetime technical support provided.

Q6: How about spare parts?

A6: We provide a spare parts list with each machine.

Q7: Can you help with custom design requirements?

A7: Yes, our experienced engineers can create customized solutions.

Q8: Can you analyze and design machines for new products?

A8: Yes, our technical department can analyze, design and test new products.

Q9: What is your order process?

A9: 30% deposit → production → testing → balance payment → shipment.

Q10: Can you send product catalog and price list?

A10: Electronic catalog available; specific pricing available upon request.

Q11: Can I visit your factory?

A11: Yes, our factory address: Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China
