1. Product Overview

The NEV Electrical System Training Platform is an integrated diagnostic station designed to pair with the NEV Chassis System Training Platform. Utilizing MIL-STD aviation connectors, it provides direct access to low-voltage circuits for real-time measurement and analysis of critical EV subsystems, including:
• Battery Management System (BMS) & Charging Networks
• High-Voltage Distribution Unit (PDU)
• Climate Control & Thermal Management
• Body Electronics (Lighting, Wipers, Access Controls)

2. Core Technical Advantages

A. Precision Diagnostics

• Aviation-grade interfaces ensure signal integrity for measuring voltage/current waveforms, CAN bus traffic, and insulation resistance.
• Color-coded test points align with schematic diagrams for rapid fault isolation.

B. Industrial-Grade Construction

• 3mm reinforced aluminum composite panels with chemical-resistant silkscreen printing.
• Ergonomic steel frame (450mm work surface) with ESD-safe coating and dual-brake casters.

C. Smart Training Integration

• Compatible with OEM diagnostic tools for authentic workshop workflows.
• Supports open/short circuit injection for failure mode analysis.

3. Pedagogical Value Proposition

Scenario-Based Learning

• Emulates 12+ real-world failure cases in BMS communication, charging handshakes, and HVAC control logic.

Cross-Disciplinary Skill Development

• Bridges high-voltage safety protocols with low-voltage system diagnostics.
• Reinforces systems thinking through chassis-electrical correlation exercises.

Certification Alignment

• Meets IMI/EATA L2/L3 competency requirements for NEV maintenance technicians.
