KYC D3 Series
The KYC D3 is a commercial light-duty truck that perfectly combines high agility with heavy-load carrying capacity. This series is engineered for short-haul urban logistics, tight neighborhood deliveries, and multi-purpose commercial transport. The standout feature of the D3 is its availability in a Double Rear Tire heavy-duty configuration. Combined with a high-strength straight-beam chassis, it delivers exceptional truck-level hauling capacity while maintaining the maneuverability of a compact mini-truck.
Core Product Highlights
  • Professional Heavy-Duty Chassis: Built on a whole-shaped, high-intensity steel straight-beam frame across all models. This exceptionally rigid structure prevents deformation under prolonged heavy loads.
  • Flexible Rear Tire Configuration: Offers a choice between a single rear tire setup (for high maneuverability) and a double rear tire setup (for heavy hauling). The double rear tire variant boosts the maximum rated payload to an impressive 1,705 kg.
  • Classic & Practical Cabin: Available in a 2-seater Single Cabin and a 5-seater Double Cabin layout. Features an ergonomic dual-pod analog gauge cluster and contoured seating to ensure daily driving comfort.
Vehicle Dimensions & Cargo Space
The D3 features compact and well-proportioned dimensions, allowing it to navigate narrow streets and congested urban areas effortlessly (all measurements in mm):
Single Cabin Models (2-Seater)
Configuration Vehicle Dimensions (L×W×H) Cargo Bed Dimensions (L×W×H) Wheelbase
Single Rear Tire 4940 × 1780 × 2010 3100 × 1680 × 360 2850 or 3250
Double Rear Tire 5650 × 1950 × 2010 3800 × 1850 × 360 2850 or 3250
Double Cabin Models (5-Seater)
Configuration Vehicle Dimensions (L×W×H) Cargo Bed Dimensions (L×W×H) Wheelbase
Single Rear Tire 5240 × 1780 × 2040 2600 × 1680 × 360 2850 or 3250
Double Rear Tire 5700 × 1950 × 2030 3100 × 1850 × 360 2850 or 3250
High-Efficiency Powertrain
The D3 series comes standard with the field-proven H16 gasoline engine, delivering an optimized balance of low-speed torque and highway fuel economy:
Engine Model H16 (Euro VI Compliant)
Fuel Type Gasoline (Optional Compressed Natural Gas / CNG dual-fuel configuration available)
Displacement 1599 cc (1.6L)
Rated Power 83 kW
Max. Torque 152 N.m
Max. Speed 110 km/h
General Mechanical Specifications
Max. Rated Payload 905 kg - 1705 kg
Gross Vehicle Weight (GVW) 2530 kg (Single Rear Tire) / 3630 kg (Double Rear Tire Heavy-Duty)
Curb Weight 1200 kg - 1600 kg
Brake System Front disc / Rear drum
Tire Specification 185R14LT 8PR
Rim Material Durable Steel
Configuration List
Basic Configurations: Electric Power Steering (EPS), Anti-lock Braking System (ABS), Daytime Running Lights (DRL), MP3 player.
Optional Luxury Package: Remote Key + Central Locking, Front Power Windows, MP5 Touchscreen + Reverse View Camera, Air Conditioning (A/C), and CNG system.
