Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Specifications
Model Number :
DZ-2243
Speed :
3S~6S (Adjustable)
MOQ :
Sample order accepted
Delivery Time :
5-10 working days after payment received
Remote Control Distance :
≤100m (open sunny weather)
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,Credit card,Paypal,Alipay,Wechat
Working temperature :
-35℃ ~ +85℃
Supply Ability :
10,000 pcs per month
Certification :
CE/ ISO
Housing Material :
3mm thickness carbon steel
Place of Origin :
Shenzhen, China.
Power Voltage :
DC24V / AC100~240V, 50/60Hz
Price :
negotiable
Housing dimension :
350*300*1005*3.0(MM)
Brand Name :
SINOMATIC
Protection Grade :
IP66
Packaging Details :
Carton/Plywood box/Pallet
Description
Durable Automatic Barrier Gate Featuring 24V BLDC Brushless Motor IP66 Dust Explosion Proof Design
This explosion-proof barrier gate features a 4th generation DC brushless motor with IP66 dustproof and waterproof rating. Specifically designed for coal mines, grain depots, chemical plants, and other combustible dust environments, it delivers stable operation with multiple safety protection functions.
Application Scope
Widely applicable to residential communities, commercial parking lots, industrial parks, scenic spots, government institutions, highway toll stations, and other outdoor public access passages. This barrier gate is an ideal choice for standardized, intelligent, and durable vehicle access management.
Core Advantages
Strict Dust Explosion-Proof & IP66 Protection
Fully sealed thickened metal enclosure prevents combustible dust from entering the motor and control chamber. IP66 dustproof and waterproof structure keeps the unit stable in rainy, dusty and humid outdoor conditions, conforming to safety standards for dust hazardous zones.
4th Generation DC Brushless Motor
  • No carbon brush wear, zero carbon dust pollution
  • Low heat generation, supports long-term non-stop operation
  • No jamming, low failure rate, greatly extend service life
  • No-load speed up to 1850R/MIN, power 200W
Rich Interfaces & Strong Expandability
Reserved multi-channel IO input/output ports + RS485 communication port. Easily connect with ground loop, radar detector, infrared photocell, traffic light, fire linkage device and parking management system. Left and right opening direction can be switched quickly without mechanical modification.
Complete Safety Protection (24 Functions)
  • Adjustable opening speed & soft start/soft stop
  • Manual release when power cuts off
  • Obstacle auto-reverse & anti-collision alarm
  • Anti-tailgating, fleet peak passage mode
  • Fire linkage emergency lifting
  • Normally open / normally closed signal output
  • Delay drop, counting, one-key cycle operation and other industrial functions
Wide Environmental Adaptability
Working temperature: -35℃ ~ +85℃
Working humidity ≤90%
Boom length optional: 3m to 6m
Wide voltage support: DC24V / AC110V / AC220V 50/60Hz
Durable Automatic Barrier Gate with 24V BLDC Brushless Motor IP66 Dust Explosion Proof and 3S~6S Adjustable Speed for Secure Parking Management
Technical Specifications
Item Specification
Product Name Brushless Dust Explosion-proof Barrier Gate
Model No. DC-WS-DZ-2243
Driving Mode DC Brushless Motor
Motor Generation 4th Generation Brushless Motor
Rated Power 200W
Motor No-load Speed 1850R/MIN
Power Supply DC24V / AC110V / AC220V, 50/60Hz
Protection Class IP66
Adaptable Boom Length 3m - 6m
Product Dimension 350*305*1005(mm)
Running Speed 3S~6S adjustable
Remote Control Distance ≤100m (open sunny weather)
Working Humidity ≤90%
Working Temperature -35℃ ~ +85℃
