Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-HRB02
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T,Western Union,,L/C,D/A,D/P
Supply Ability :
100pcs per month
Delivery Time :
5-7 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Control Voltage :
24V
Buffer Time :
0.2s-0.5s
Protection level :
IP68
Power supply :
380V
Starting Time :
≤ 2S
Warranty :
12 months at least
Description
A3 Steel Security Rating Remote Control Hydraulic Automatic Road Blocker
Hydraulic road blockers (also known as anti-terrorism walls) provide high-security vehicle access control. These systems prevent unauthorized vehicle entry with exceptional reliability and security. Available in various configurations to meet specific site requirements, they feature emergency release systems for power outages, allowing normal vehicle passage when needed.
Installation Requirements
Installation requires pavement width matching the intersection dimensions. Standard sizes include: 2m, 2.5m, 3m, 3.5m, 4m, 4.5m, 5.5m, and 6m. Each 3 meters is counted as one piece, with custom lengths available for special requirements.
Applications
Widely used in highway toll stations, checkpoints, prisons, airports, government agencies, embassies, bases, customs, banks, industrial facilities, ports, warehouses, parking lots, and all locations requiring vehicle traffic restriction.
Product Specifications
Product Name Road Blocker/Road Barrier
Vehicle Capacity 80T Truck
Operating Temperature -45℃ to 65℃
Relative Humidity ≤ 95%, No Condensation
Response Time ≤ 3 Seconds
Power Requirements 3.7KW/380V, Three-phase and Single-phase
Motor Type Hydraulic Motor
Storage Environment -40℃ to 75℃, Rainproof, Moisture Resistant, Dustproof
Construction Material A3 Steel with Rustproof Lacquer
Protection Rating IP68
Standard Dimensions
L3000 × W1000 × H760 mm (Rising height: 500mm)
L3500 × W1000 × H760 mm (Rising height: 500mm)
L4000 × W1000 × H760 mm (Rising height: 500mm)
L4500 × W1000 × H760 mm (Rising height: 500mm)
L5000 × W1000 × H760 mm (Rising height: 500mm)
L5500 × W1000 × H760 mm (Rising height: 500mm)
L6000 × W1000 × H760 mm (Rising height: 500mm)
Main Features
  • Hydraulic control system with multi-language LCD display
  • Power supply: 380V (control voltage 24V)
  • System power: 3.7KW
  • Pressure capacity: Maximum 120 tons for container trucks
  • Anti-collision rating: K12 (withstands 120KM/h impacts)
  • Protection level: IP68 (dustproof, waterproof)
  • Operation time: 3-6 seconds (adjustable)
  • Communication: RS485 ≤ 1200M
  • Elevation range: 450mm-800mm
  • Working temperature: -45°C to 75°C
  • Storage environment: -10°C to 75°C, rainproof, moisture proof, dustproof
  • Weight: 2200kg-5500kg approximately

Rustproof Lacquer A3 Steel Hydraulic Road Blocker with 0.5s Buffer Time for High Security

Additional Functions
  • Manual operation capability during power outages
  • Gang-control interface for multiple unit coordination
  • Reliable heavy-duty structure with smooth, low-noise operation
  • Reversible operation during rising and falling cycles
  • Hydraulic drive with hydraulic lock mechanism
  • PLC programming command control system
  • LCD display with multi-language menu options
  • PLC built-in encryption system for security
  • Double dynamic double oil pump (2.3ML/time)
  • High-pressure hydraulic hose with PT international interface
