Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-SL03
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
Sample order accepted
Price :
Negotiable
Payment Terms :
T/T,Western union,Visa,MasterCard,PayPal,Stripe,PayPal_BNPL,Apple pay,Google pay,Pix,OXXO,Billie,Online Transfer etc. Alipay
Supply Ability :
1000 pcs/ month
Delivery Time :
5~10 days
Packaging Details :
Crate
Housing dimension :
1200x330x1000mm(default)
Barrier height :
Standard 1500mm
Barrier material :
Clear acrylic
Channel width :
550mm
Power consumption :
Max 100W
Power supply :
AC 100V-240V
Description
Anti Crawling Full Height Turnstile 550mm Channel Sliding Glass SS304
Product Overview
The optical sliding barrier is engineered to control pedestrian access in restricted areas, ideal for high-traffic environments requiring bidirectional flow management. Constructed from brushed stainless steel, it provides a seamless and elegant access solution that complements modern indoor settings.
Integration & Emergency Features
This turnstile seamlessly integrates with various access control systems including RFID devices, push buttons, fingerprint scanners, and biometric devices. In emergency situations, the barrier arm automatically opens to ensure unrestricted passage, making it suitable for sophisticated entrance solutions.
Key Functions & Features
  • Smooth system operation with long-life performance, high reliability, and rapid response
  • Multiple operational modes: bidirectional card reading, unidirectional card reading, and free passage options
  • Automatic barrier opening during power loss and automatic closure upon power restoration
  • Adjustable closing delay from 1-60 seconds after valid card reading
  • Automatic reset function cancels user authority if passage isn't completed within set time
  • Audible alarm activation for unauthorized passage attempts
  • 485 interface for long-distance control capabilities
  • Anti-rush function maintains barrier position without open signal
  • Dual anti-clipping protection: photocell detection and mechanical safety mechanisms
  • Standard electrical interfaces for reader integration
  • Optional passenger counting with LED display
  • Directional display guidance for user navigation
  • Card-reading with or without memory function
Technical Specifications
Item Specifications
Brand SINOMATIC from SHENZHEN CHINA
Standard Dimension 1200x330x1000mm
Framework Material SS304
Material Thickness 1.2mm minimum
Panel Material Acrylic
Panel Thickness 10mm
Passage Width 550mm (default)
Passing Direction Single directional/Bi-directional
Pass Rate 30 persons per minute
Operating Time 0.2 seconds
Power Input AC100-240V, 50/60HZ
Working Voltage 24V
Working Humidity 5%~95%
Working Temperature -25℃~+60℃
Working Environment Indoor/outdoor with tent
Communication Interface Dry contact
Mechanism Brushless motor
Infrared Sensor 4 pairs (default)
MCBF 5,000,000 Cycles
Application Airports, Hotels, Government Halls, etc.
Anti Crawling Full Height Turnstile with 550mm Channel and SS304 Sliding Glass Access Control
