3.7KW Hydraulic Road Blocker with RS485 Communication and IP68 Protection for Vehicle Control
3.7KW Hydraulic Road Blocker with RS485 Communication and IP68 Protection for Vehicle Control
3.7KW Hydraulic Road Blocker with RS485 Communication and IP68 Protection for Vehicle Control
3.7KW Hydraulic Road Blocker with RS485 Communication and IP68 Protection for Vehicle Control
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-HRB02
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T, Western Union, , L/C, D/A, D/P
Supply Ability :
100pcs per month
Delivery Time :
5-7 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Product :
road block
Control Voltage :
24V
Buffer Function :
Buffer Time :0.2s-0.5s
Protection level :
IP68
Power supply :
380V
Starting Time :
≤ 2S
Description
Hydraulic RS485 3.7KW Access Control Road Blocker
Automated hydraulic road blocker system designed for high-security vehicle access control with IP68 protection rating.
Technical Specifications
Control SystemHydraulic
Power Supply Voltage380V (Control Voltage 24V)
System Power3.7KW
Pressure CapacityMax. 120 tons of container trucks
Anti-collision RatingK12 (equivalent to 120KM/hour impact)
Protection LevelIP68 (dustproof, waterproof)
Opening Time1-3 seconds (adjustable)
Closing Time2-3 seconds (adjustable)
CommunicationRS485 ≤ 1200M
Elevation Height450mm-800mm
Working Temperature-45°C to 75°C
Hydraulic pressure is adjustable, normal pressure should be adjusted below 50KGF, maximum cannot exceed 70KGF.
Storage environment: -10°C to 75°C, rainproof, moisture proof and dustproof.
Product Overview
The road blocker automatically lifts and lowers through inductive detection, remote control, or manual button operation to effectively prevent unauthorized vehicle intrusion and control road traffic.
Applications
Widely used in highway toll stations, checkpoints, prisons, airports, government agencies, embassies, bases, customs, banks, industrial and mining enterprises, ports, warehouses, parking lots, and all locations requiring vehicle traffic restrictions.
3.7KW Hydraulic Road Blocker with RS485 Communication and IP68 Protection for Vehicle Control
Standard Dimensions
Available in multiple standard sizes with 500mm rising height (customizable):
L3000×W1000×H760mm
L3500×W1000×H760mm
L4000×W1000×H760mm
L4500×W1000×H760mm
L5000×W1000×H760mm
L5500×W1000×H760mm
L6000×W1000×H760mm
Key Features
  • Hydraulic control system with multi-language LCD display
  • 380V power supply with 24V control voltage
  • 3.7KW system power
  • Maximum pressure capacity: 120 tons
  • K12 anti-collision rating (120KM/hour impact resistance)
  • IP68 protection level (dustproof, waterproof)
  • Opening time: 3-6 seconds (adjustable)
  • Closing time: 3-6 seconds (adjustable)
  • RS485 communication up to 1200M
  • Elevation height: 450mm-800mm
  • Operating temperature: -45°C to 75°C
  • Storage environment: -10°C to 75°C
  • Weight: 2200kg-5500kg approximately
Additional Functions
  • Manual operation capability during power outages
  • Gang-control interface
  • Reliable heavy-duty structure with smooth, low-noise operation
  • Reversible operation during rising and falling cycles
  • Hydraulic drive with hydraulic lock mechanism
  • PLC programming command control system
  • LCD display with multi-language menu support
  • PLC built-in encryption system
  • Double dynamic double oil pump (2.3ML/time)
  • PT international interface hydraulic oil hose (1/2" double wire high pressure)
