Automatic 304 Stainless Steel Full Height Turnstile with 30 Person Per Minute Flow Rate and Bi-directional Access Control
Automatic 304 Stainless Steel Full Height Turnstile with 30 Person Per Minute Flow Rate and Bi-directional Access Control
Automatic 304 Stainless Steel Full Height Turnstile with 30 Person Per Minute Flow Rate and Bi-directional Access Control
Automatic 304 Stainless Steel Full Height Turnstile with 30 Person Per Minute Flow Rate and Bi-directional Access Control
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-SL01
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
Sample order accepted
Price :
Negotiable
Payment Terms :
T/T,Western union,Visa,MasterCard,PayPal,Stripe,PayPal_BNPL,Apple pay,Google pay,Pix,OXXO,Billie,Online Transfer etc. Alipay
Supply Ability :
1000 pcs/ month
Delivery Time :
5~10 days
Packaging Details :
Crate
Product type :
Sliding barrier
Thickness of housing :
1.2mm or 1.5mm
OEM/ODM :
supported
Application :
indoor/outdoor with tent
Lane length :
550mm
Warranty :
1 year
Standard :
CE
Material of housing :
304 or 316 stainless steel
Direction :
Single or bi-direction
Max flow rate :
25 to 30 person per minute
Description
Automatic Elliptical Synchronization Full Height Turnstile For IC / ID Card Readers
1.2mm thickness 304 stainless steel full height sliding gate access control turnstiles
Product Overview
The elliptical design of our full height sliding turnstile emphasizes natural visitor movement through the lane, ensuring a comfortable user experience. Available in different heights to adapt security levels in your lobby. Features quick sliding motion and integrated authorization memory for high capacity throughput of 30 people per minute.
Applications
Suitable for indoor or outdoor installations with protective covering. Optimized solution for airports, railway stations, metro stations, factories, colleges, commercial buildings, libraries, stadiums, hotels, banks, and similar facilities.
Key Features
  • Fault detection and alarm functions for easy use and maintenance
  • Programmable running status controlled via built-in keyboard on main board
  • Mechanical anti-pinch function with automatic motor stop and reset
  • Anti-breakthrough function with automatic locking until opening signal received
  • Synchronization functions for dual gate equipment
  • Automatic reset function cancels authority after preset time (default 5 seconds)
  • Configurable as normally open or normally closed
  • Compatible with various card readers: IC/ID card readers, bar codes, fingerprints (access controller required)
  • Direction configurable as single-direction or bi-direction
  • LED direction indicator
  • Automatic power-off opening and power-on closing for fire safety compliance
  • Alarm function for illegal intrusion and reverse intrusion detection
  • Optional counter function
  • Supports infrared photocell for anti-pinch and reset functions
Technical Specifications
Power Supply AC220±10%V 50Hz/AC110±10% 60Hz
Access Device Input Voltage Dry contact or 12V electrical level signal or > 100ms 12V impulse signal, driving current > 10mA
Motor Voltage DC 24V (brush motor)
Maximum Flow Rate 25 to 30 persons per minute
Flap Opening / Closing Time 1 second
Reset Time When Power On 3 seconds
Working Temperature -20°C to 60°C
Product Image
Automatic 304 Stainless Steel Full Height Turnstile with 30 Person Per Minute Flow Rate and Bi-directional Access Control
Why Choose Our Full Height Turnstiles
  • Over 20 years of OEM/ODM experience in access control turnstiles and barriers
  • Prompt delivery with standard model inventory
  • OEM/ODM orders accepted to meet client requirements
  • Trial orders available for testing before bulk orders
  • Online technical support for business partners
  • Multiple transportation options: sea shipment, air cargo, or express
  • Factory visits welcome on working days
