500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
Specifications
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Spraying Area :
500x400x350mm
Positioning Accuracy :
±0.2mm
Electrical Components :
CHINT, Delixi, Omron
Power Supply :
Hugong
Rated Voltage :
220VAC/50Hz
MOQ :
1
Spray Gun :
ManSheng Blue Gun 1.3mm
Price :
USD12765
Machine Dimensions :
2143x1500x2170mm
Air Pressure :
0.6-0.8MPa
Exhaust Port :
Round 400mm
Certification :
CE
Weight :
480KG
Control Button :
TEND
Drive Mode :
8-Axis Precision Servo
Motor :
Xinje
Pneumatic Components :
SNS, AirTAC
Packaging Details :
wooden box
Spraying Mode :
360° Tray Rotation + Reciprocating
Motion Module :
High-Precision Motion Module
Axis Configuration :
X,Y,Z,R,A,T1,T2,W
Program Storage :
10000 Programs
Brand Name :
ManSheng
Body Material :
Stainless Steel, Aluminum, Steel
Touch Screen :
Kunlun Tongtai
Control System :
ManSheng Touch Screen
Power Consumption :
4.5KW/H
Description
500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine
The 500X8 is a heavy-duty 8-axis high-speed reciprocating automatic spray painting machine, engineered for large-scale industrial surface coating applications. Featuring an advanced servo drive system with 360-degree tray rotation, it delivers exceptional throughput with ±0.2mm positioning accuracy. The robust 480KG construction ensures stability and durability for continuous production environments.

Key Highlights

Drive System

8-Axis Precision Servo

Accuracy

±0.2mm

Spray Gun

ManSheng Blue Gun 1.3mm

Spraying Mode

360° Tray + Reciprocating

Program Storage

10,000 Programs

Spraying Area

500 * 400 * 350mm

Technical Specifications

ParameterSpecification
Model500X8
Body MaterialStainless Steel, Aluminum, Steel
Weight480KG
Machine Dimensions2143 * 1500 * 2170mm
Spraying Area500 * 400 * 350mm
Positioning Accuracy±0.2mm
Axis ConfigurationX, Y, Z, R, A, T1, T2, W (8-Axis)
Rated Voltage220VAC / 50Hz
Air Pressure0.6-0.8MPa
Power Consumption4.5KW/H
Exhaust PortRound / 400mm

Premium Components

ComponentBrand / Spec
MotorXinje
Motion ModuleHigh-Precision Motion Module
Pneumatic ComponentsSNS, AirTAC
Electrical ComponentsCHINT, Delixi, Omron
Power SupplyHugong
Touch ScreenKunlun Tongtai
Control ButtonTEND
