Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Specifications
Place of Origin :
Shanghai, China
Brand Name :
YIMU
Certification :
SGS/CE
MOQ :
1
Price :
$10,000-15,000
Voltage :
220V/380V
Dimension :
2000(L)*900(W)*1700(H) mm
Labeling speed :
20-60 Bottles/min
Label width :
5-240mm
Label length :
5-500mm
Labeling accuracy :
0.5 mm error
Weight :
250 KG
Conveyor speed :
0-30m/min
Bottle diameter :
Below 120mm
Power supply :
700W, 110V/220V, 50/60Hz, 1 phase
Label reel inner diameter :
76mm or 40mm
Label reel outer diameter :
Max 380mm
Machine size :
L2000 * W800 * H1750 mm
Machine net weight :
250KG
Core components :
PLC, motor
Description
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
1
Label width(height)
10-180mm
2
Label length
20-500mm
3
Capacity
0- 60 bottles/min
4
Conveyor speed
0-30m/min
5
Labeling accuracy
±0.5mm
6
Bottle diameter
Below 120mm
7
Power supply
700W, 110V/220V, 50/60Hz, 1 phase (customized)
8
Label reel Inner diameter
76mm or 40mm
9
Label reel outer diameter
Max 380mm
10
Machine size
L2000 * W800 * H1750 mm
11
Machine net weight
250KG
12
Date printer
Optional
13
Transparent sensor
Optional
PLC
SIEMENS / MITSUBISHI
HMI
SIEMENS / WEINVIEW
Label feed motor
RAYNEN servo motor / KINCO stepper motor
Label sensor
SICK / FOTEK
Bottle sensor
SICK / KEYENCE / PANASONIC
Motor
Taiwan Taibang
Frequency changer
Taiwan Delta
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
Automatic Round Bottle Labeling Machine with Visual Camera Positioning
1, For automatic labeling on round bottles/jars/cans for the pharmaceuticals, daily chemicals, food & beverages industries.

2, The machine can connect with other machine using or using it alone.

3, English language HMI oerpation page, with 10 sets parameter save for different kind bottle, easy to operate.

4, Machine conveyor can suitable for different size bottles, and big labeling head sutiable different size labels, Max.label height 300mm.

4, Labeler will automatically detects the label size and bottle diameter and set the appropriate labeling parameters, a very useful feature for users with multiple products to label.

6, It is an optimal combination of speed, accuracy, stability, GMP standards, ease of use, and flexibility.

6, Backed by a strong engineering team who is ready to provide custom solutions for the unique production needs of different customers.
