Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
Specifications
Brand Name :
YIMU
Model Number :
CM140
Certification :
CE
Place of Origin :
Shanghai
MOQ :
1set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, Western Union
Supply Ability :
20set/month
Delivery Time :
12-15 working days
Packaging Details :
wooden case, L2000*W800*H1700mm, 300KG
Product name :
Automatic Linear Four Wheel Round Cap Capper Plastic Bottle Screw Capping Machine
Function :
four wheel capping machine
Bottle type :
any shape bottle (100-5000ml)
Material :
SUS316 + SUS034
Capping speed :
25-45 bottles/min
After-sales service provided :
Online Video technical support,Free spare parts
Driven type :
Pneumatic, Electric
Application :
Chemical,Commodity
Description

Automatic Linear Four Wheel Round Cap Capper Plastic Bottle Screw Capping Machine

Equipment Description:
  1. The linear capping machine has high capping speed, high pass rate and easy operation.
  2. Applicable to different bottle-shaped screw caps in food, pharmaceutical, daily chemical, pesticide, cosmetics and other industries.
  3. Four speed-regulating motors are used for cap feeding, bottle clamping, conveying and capping.
  4. The machine has a high degree of automation, good stability, and easy adjustment.
  5. No spare parts are required when changing the bottle shape or cap, and it can be done by adjusting.
  6. Four wheel type screwing cap, it is very easy for adjustment and suitable for many different size and shape cap, no need to change spare parts.
Technical Parameter:
Cap feeding device
Cap elevator or Vibration disk
Capping type
Servo electric clamp control four wheel screwing
Bottle height
60-320mm
Cap diameter
20-120mm
Bottle diameter
30-150mm
Capping speed
25-45 bottles/min
Capping voltage
AC 220V 50/60Hz,1 phase, (customized)
Air pressure
0.3-0.8MPa
Dimension
2000(L)*1000(W)*2000(H)mm
Packing size
2100(L)*1100(W)*1700(H)mm
Machine weight
About 500KG

Drawing:

Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap

Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap

Customized Linear Trigger Pump Capping Machine For Four Wheel Round Spray Cap
