200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
Specifications
Brand Name :
Haitel
Model Number :
HTL-480A
Certification :
CE SGS ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10 pcs per month
Delivery Time :
30 days
Packaging Details :
Sea-Worthy Packing or Air-Worthy Packing
Packing speed :
100~300 bags/min
Membrane width :
≤480mm
Voltage :
380V/50Hz
Total power :
4 KW
Motor power :
1.5 KW
Heating power :
2.5 KW
Description

automatic servo motor fresh vegetables packaging machines stainless steel

Characteristics:

1.Full computer controlled, frequency conversion controls speeding, high detective photoelectric device, independent sealing temperature control, applicable to many packaging material, mechanical simplicity, easy to maintenance, low wearing, long service life.

2.Feeding paper from bottom, it has push feeder (HTL-480A) and membrane feeder (HTL-480B) types.

Application:

It is applicable to special packing for soft and long products like instant noodle, wet tissue, bread, meet, chicken meet, dried noodle, egg roll, soft candy, fresh fruit and towel.

Main technical parameter

Mode HTL-480A/480B
Making-bag size (L)=70~360mm, (W)=30~120mm, (H)=3~50mm
Packing speed 100~300 bags/min
Membrane width ≤480mm
Voltage 380V/50Hz
Total power 4 KW
Motor power 1.5 KW
Heating power 2.5 KW
Dimension (L*W*H) 4800×950×1150 mm
Total weight 1000 kg

HTL-480 Main collocate

①PLC and touch screen: Taiwan

② Photoelectricity switch: Yatai

③ Transducer: Yatai

④ Push button: Delixi

⑥ Temperature controller: Delixi

⑦Approach switch: Delixi

⑧Servomotor: Taiwan

⑨Motor: Zhongweite

HTL-480 spare parts list (FREE)

1. Electric heating tube 2

2. Electric heating circle 1

3. Electric thermal couple 1

4. Conveying claw 5

5. Cutting knife 2

6. Internal hexagonal spanner 1

7. Oil gum 1

8. Opening spanner 1

9. Certificate of inspection 1

10. Manual 1

Machine pictures

200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW

200 Bags/Min SS Vegetable Horizontal Wrapping Machine 4KW
