Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Specifications
Warranty :
1 Year
Type :
Other
Applicable Industries :
Hotels, Manufacturing Plant, Food & Beverage Factory, Food Shop
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Motor
Application :
Food, Machinery & Hardware
Packaging Type :
Cartons
Packaging Material :
Plastic, Wood
Automatic Grade :
Semi-automatic
Driven Type :
Electric, Electric
Voltage :
380/220V, 380/220V
Power :
2kw, 2kw
Place of Origin :
China
Brand Name :
M&J
Weight :
1000kg, 1000kg
Dimension(L*W*H) :
1500*980*3700mm, 1500*980*3700mm
Key Selling Points :
Easy to Operate
Product Name :
bulk cement loading spout
Color :
blue and white,or as customer's request
Weighing range :
10~25,25~50kg/bag
Output :
400~500bags/h
Air power :
0.4~0.6Mpa
After Warranty Service :
Video technical support, Online support
Local Service Location :
None
Marketing Type :
Ordinary Product
After-sales Service Provided :
Video technical support
Certification :
CE,ISO9001,CQC,CIQ
Packaging Details :
packed by export standard plywood cases silo chute
Port :
Shanghai port,bulk truck loading chute
Supply Ability :
35 Set/Sets per Month bulk cement loading spout
Price :
$3,000.00 - $5,000.00/sets
MOQ :
1 set
Description
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
The telescopic chute adopts double casing structure, which is composed of chute and dust cover. The material passes through the chute, and the dust cover is covered on the chute. During the process, the dust suction chamber is moved. The bottom of dust-free telescopic chute will be provided with material level sensor and dust-proof group cover. The material level sensor will be set on the outside or inside, and the dust cover will be of block overlap type. In the loading process, after the material level sensor contacts the material, the dust-free telescopic chute will be lifted in time to keep a certain distance between the material top and the accumulated materials. The dust-proof group cover can cover the material pile to ensure the dust collection effect and prevent dust overflow. The chute will be made of steel plate with polyurethane wear-resistant lining plate, and the dust cover is made of chemical fiber material with anti-static soft strength. A supporting framework will be set in the dust cover, which can not only stretch up and down, but also ensure smooth air flow. At least three lifting points will be set at the bottom of the telescopic chute to ensure that the lifting mechanism drives the telescopic chute to rise and fall smoothly.
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Product brand
M&Jmachinery
Range of ingredients
1-200KG
Batching speed
depends on the material and weight
Screw speed
40~85r/min
Helix diameter
Φ100~Φ400
Power supply
AC380V.50HZ
accuracy
0.2%
Working conditions
Temperature - 10 ~ 40 ℃, humidity: < 90%
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
Electric Driven High Automated Telescopic Chute Bulk Cement Loading Spout
