Components and Features

1.Paper feeding part :Pre code paper, paper feeding platform, pneumatic bench

Pre code paper:

The cylinder-sliding aluminum angle device is easy and quick to operate. The operator only needs to put the processed paper into the pre-stacking paper cart, and when the paper reaches the lower limit, put the paper cart back on the paper feeding platform and continue with the next step.

Paper feeding platform:

The automatic lifting step can be set according to the amount of paper, which is easy and quick to operate. It has the characteristics of short paper feeding distance and low labor intensity.

Pneumatic bench:

The operator stands on the working platform and the machine height is pneumatically adjusted according to the operator's height, which is easy to operate and saves time and effort..

2. Positioning part: the front guide, the side guide.

Front guide:

he integrated, swinging front-swing side paper guide minimizes impact on paper edges and offers high positioning accuracy. Equipped with four precision fiber optic switches (Taiwan Ligong brand), they effectively detect paper placement and prevent paper waste.

Side guide:

You can choose side guides according to different products, no need to replace parts, and adjustment is convenient and quick.

3. Die cutting part: transmission structure, intermittent structure, pneumatic clutch brake.

Transmission structure:

A brand-new transmission design enables high-speed, precise die-cutting.

The main drive utilizes a worm gear transmission and a specially designed crankshaft-connecting rod structure.

The bearing connection reduces play and prevents impact from the worm gear.

High die-cutting pressure is achieved, with high-pressure capability. Pressure-reducing buffer springs are installed at the four corners of the moving platform to reduce machine wear and ensure smoother operation.

Intermittent structure:

It utilizes a high-precision parallel three-dimensional cam indexing structure.

The cam curve is specially designed and features a large feed angle for smoother gripper operation.

Pneumatic clutch brake:

The torque is transmitted by adjusting the air pressure, which has low noise and good braking performance. The machine will automatically shut down when overloaded to avoid accidents.
