Horizontal Packing Machine Manufacturers Coffee Beans Granule Premade Zipper Bag Doypack Packaging Machines
Horizontal Packing Machine Manufacturers Coffee Beans Granule Premade Zipper Bag Doypack Packaging Machines
Specifications
Brand Name :
LTPM CHINA
Model Number :
HorizonTop-Series
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 sets/ month
Delivery Time :
25
Packaging Details :
Wooden Case
Type: :
Packing Machine
Application :
food,daily chemical etc
Automatic Grade: :
Automatic
Dimension(L*W*H): :
2200x1850x1700mm
additional function :
hanging hole,special shape
Packing speed: :
40-60 bags/min
Control :
PLC+ Touch Screen+Inverter
Weight(kg) :
2000
Description

Products Description:

Workflow
1. Upper bag. 2 Bag opening. 3 Blanking. 4 Add liquid. 5 Reserved. 6 Reserved. 7 Ferry bag. 8 Reserve one (vacuum);
1. Bag connection. 2 Close the cover. 3 Primary vacuum. 4 Secondary vacuum. 5 tertiary vacuum. 6 Four times of vacuum. 7 sealing, 8 Seal cooling. 9 Bleed. 10 Open the lid and take out the bag

Main performance and characteristics

1. The automatic vacuum packaging machine is composed of two separate rotary bodies (filling system and vacuum system respectively);

2. Convenient operation: it adopts PLC touch screen control and man-machine interface operation system, which is intuitive and convenient to operate;
3. Convenient adjustment: fully automatic Just input the required parameters from the man-machine interface, and all parts of the packaging machine can be adjusted to the part of the required command;
4. High degree of automation: meet the requirements of full-automatic vacuum, realize unmanned in the process of weighing and packaging, and give an automatic alarm of war barrier;
5. The perfect prevention system can intelligently detect whether the bag is opened and whether the bag is complete. If it is not suitable to add materials, it will not be heat sealed Do not waste bags and materials and save costs;
6. The equipment meets the hygienic standard of food processing machinery, and the contact part between the equipment and materials is processed with 304 stainless steel or other materials that meet the requirements of food hygiene.
7. Use prefabricated packaging bags with high sealing quality and improve the grade of finished products;
8. Scope of applicable packaging materials: a variety of measuring scales can be selected to package small fish, pickles, nuts, fried goods, spicy puffing, liquid and other materials.
Applications & Bag types:
It is new-updated compact version pouch pick fill seal packing machine for various pre-made bags such as pillow bags, gusset bags,zipper bags etc.As a cost saving solution, it is ideal for a lot of applications such as coffee, frozen foods, cookies,cereals, nuts, flowers,candies, liquid etc. It can also be interfaced with other equipment for use with turnkey lines.
Technical Data:
Main technical parameter
Food forming,filling material, vacuum sealing, printing date, cutting automatically.
Pouch Type
Stand-up bag, Gusseted bag, Handle bag, Spout bag, Paper bag, Zipper bag (for option)
Working Station
Six working station
Pouch
100-450mm
Capacity
Up to 50 bags/ min (product property and filling range count)
Filling Range
0-3000g
Voltage
C380V/50Hz, three phases (or customize according to specific demands)
Power
3.5KW
Air Sourse
0.4 CBM/ min (offered by the user)

Application:

Horizontal Packing Machine Manufacturers Coffee Beans Granule Premade Zipper Bag Doypack Packaging Machines
