Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items
Specifications
Brand Name :
TAISHENG
Model Number :
TS9080-2A
Certification :
ISO9001-2015
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30 sets per month
Delivery Time :
15-20 days
Packaging Details :
Pallet / Wooden + PE + ABF,
Type :
Automatic
Material :
Carbon Steel
Qty of Guns :
2 pcs
Dust collector :
Bags
Qty of Drums :
2 pcs
Dia of Nozzle :
8mm
Description

Rotary Drum Sandblast Machine TS9080-2A Automated Blast Cabinet with 2 guns

1. Applications

Sand blast cabinet with rotary drum are used for whole treatment of small metallic items, plastic and thermosetting parts, such as fastener, nuts.

2. Description:

The pieces to be treated are placed inside a drum, which has particular form and tilt. The rotation is assure by speed motor variate. The cycle includes: sandblasting and blow for dusting of the treated pieces. While the parts slowly tumble, two or three guns shoot the abrasive/micro balls against pieces, which, at the end of the cycle, are uniformly treated. Usually one can obtain very good results by applications shorter than 6-7 min/batch. The whole treatment cycle is completely automatic and is controlled by proper timers, programmable by means of suitable electrical device.

Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items

Advantage:

● In basket-blast batch processing machines, all surfaces of components are exposed to impact treatment as the parts gently turn over and over in a slowly rotating tilted basket.

● Basket Blasters automate cleaning, peening and finishing of small workpieces. With certain types of parts, no other finishing method can compare to these heavy-duty production machines in terms of speed and quality results.

● Operation is simple: Load parts into the unit, set the precision timer, and the Basket Blaster does the rest. By tumbling parts within abrasive blast streams, these machines deliver consistent finishes - automatically.

● Equip with abrasive recycle unit and dust collector, which ensure the less abrasive consumption and good working environment.

Rotary Drum Automated Sandblasting Equipment , Blast for Small Metallic Items

Technologies

No. Item Specification
1 External Size 1100mm x 900mm x 1600mm(L×W×H)
2 Cabinet Size 900mm x 800mm x 580mm(L×W×H)
3 Power Supply 220V,50HZ
4 Light 15*2 W
5 Compress Air Working Pressure 5-7bar(kg/cm2)； Air Consumption 2-3m3/min dry compressed air
6 Fan 750W
7 Air Volume 0.8-1.2m³/min
8 Dust Collector Bag Filter (Option: Cartridge Filter)
9 Drum Maximum Bearing 30kg
10 Gross Weight 350kg
