White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
Specifications
Brand Name :
ZHONGZHI
Model Number :
174923-1
Certification :
TS16949
Place of Origin :
China
MOQ :
100pcs/bag
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
300K pcs per month
Delivery Time :
5-8 working days
Packaging Details :
paper box and carton
Material :
PBT
Pin Number :
6 Pins
Color :
White
MOQ :
100pcs/bag
Application :
Automotive
Gender :
Female
Shape :
As shown in Figure
Sample :
Free
Description

Female Automotive Wire Connectors 6 Pins TS16949 Certification

Product Overview

Part Number Pin Number Material Color Applicable Terminal MOQ
174923-1 6 Pins PBT White 100

Product Type Features

  • Connector Style : Housing for female terminals

  • Connector System : Wire-to-Wire

  • Sealable : No

  • Hybrid Connector : No

  • Primary Locking Feature : Integrated in Housing

  • Strain Relief : No

Configuration Features

  • Number of Positions : 6

  • Number of Rows : 1

Electrical Characteristics

  • Nominal Voltage Architecture (V): 12

  • Operating Voltage (VDC): 12

Body Features

  • Color : Natural

  • Cable Exit Angle : 180°

  • Body Material : PBT

Contact Features

  • Mating Tab Width : 1.8 mm [ .071 in ]

Mechanical Attachment

  • Mounting Feature : Without

  • Terminal Position Assurance : Yes

  • Polarized : Yes

Housing Features

  • Centerline (Pitch) : 3.5 mm [ .138 in ]

Dimensions

  • Width : 24.4 mm [ .961 in ]

  • Height : 15.9 mm [ .626 in ]

  • Length : 21.6 mm [ .85 in ]

Usage Conditions

  • Operating Temperature Range : -30 – 105 °C [ -22 – 221 °F ]

Operation/Application

  • Circuit Application : Signal

Industry Standards

  • UL Flammability Rating : UL 94-HB

Packaging Features

  • Packaging Method : Bag

  • Packaging Quantity : 100

Other

  • Connector Position Assurance Capable : No

  • Serviceable : Yes

.White Color Female Automotive Wire Connectors 6 Pins TS16949 Certification
