Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Multi Function Dried Fruit Food 10 Head Weigher Packing Machine
Specifications
Price :
Negotiable
Packing bag size :
W ：80 - 200mm L : 100 - 360 mm
MOQ :
Negotiable
Total power :
6 kw
Payment Terms :
D/A,D/P,T/T,Western Union,
Power supply :
AC220V / 50Hz , single phase
Supply Ability :
100 Set/Month
Name :
Weigher Packaging Machine
Air consumption :
≤ 0.6m³ / min
Speed :
20 - 80 packs / minute
Delivery Time :
15 - 25 / day
Quantitative range :
10 - 2000g
Place of Origin :
China
Weighing hopper volume :
3L
Accuracy :
± 0.2 - 2g
Brand Name :
Shiyuan
Certification :
CE
Voltage :
380V
Packing speed :
16 - 60 bags / min
Description

Multi Function Dried Fruit Food 10 Head Weigher Packaging Machine

Main Features


1. Special sensors with high precision and high standard are adopted.
2. Intelligent multi-sampling stable mode, more accurate weighing.
3. Intelligent fault alarm prompt, more convenient maintenance.
4. High speed asynchronous discharging function, effectively prevent material blocking.
5. New high integration modular design, using CAN bus technology.
6. Modbus industry standard communication protocol, realize combination weighing and packaging machine interface into one.
7. Other features of the same generation of models.

Technical Feature


1. The amplitude of vibrator can be auto-modified for more efficient weighing.
2. High precise digital weighing sensor and AD module have been developed.
3. Multi-drop and succeeding drop methods can be selected to prevent puffed material blocking the
hopper.
4. Material collecting system with junction of unqualified product remove, two direction discharge, counting, restore default setting.
5. Multi-language operation system can be selected basing on customer's requests.

Multi Head Weigher Specification

Packing speed 16 - 60 bags / min
Packing bag size W : 80-200mm L : 100-360 mm
Air consumption ≤ 0.6m³ / min
Voltage 380V
Total power 6 kw
Quantitative range 10 - 2000g
Weighing hopper volume 3L
Speed 20 - 80 bag / min
Accuracy ± 0.2 - 2g
Power supply AC220V / 50Hz , single phase
