2KW 400ml Automatic Liquid Packing Machine , Fruit Juice Packaging Machine 250kg
2KW 400ml Automatic Liquid Packing Machine , Fruit Juice Packaging Machine 250kg
2KW 400ml Automatic Liquid Packing Machine , Fruit Juice Packaging Machine 250kg
2KW 400ml Automatic Liquid Packing Machine , Fruit Juice Packaging Machine 250kg
Specifications
Brand Name :
Shiyuan
Model Number :
SLIV-380D
Certification :
CE
Place of Origin :
Foshan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
15-25/day
Delivery Time :
100 Set/Month
Packaging Details :
1260 * 940 * 2350mm
Name :
Automatic Liquid Packing Machine
Packing material :
NILO/PE PE
Bag size :
( W ) :30 - 150mm（ L ）: 30 - 170mm
Packing speed :
( W ) : 30 - 150mm ( L ) : 30 - 170mm
Measuring range :
400ml
Voltage :
220V or 380V50 - 60HZ
Power :
2KW
Dimension :
L930 x W730 x H1700mm
Weight :
250kg
Description

Filling Juice Drinks Liquid Packing Machine

Production properties


It is suitable for automatic packing of lose nonstick, granular and thick powder production in the pharmarceeuical, the food, the plant germ, the chemical products such as instan drink,peiiet,monosodium glutamate,white sugar,soup coffee wheat groats etc.

Working Process
The working processes include: The machine pull laminate packaging film to the pouch forming devices, and go through the vertical sealing plate, in the meanwhile, the dosing device dose the product into the pouch, then will do the horizontal sealing and cutting off. Above is the typical working process diagram.

Main features


1. This machine has been adopted a PLC programmer control and provided whit a Chinese character displayer. Thus, this equipment is easy to poerate and convenient adjustment,with high automation.
2. This advance digital photo electrical buymaking system an make the length of bag set diectlyat the operation bench,when you are using the materials whit color mark,the first can catch the color mark,which can obtain accurate trademark and pattern.The synchronous bag pulling system can make bag pulling steady and accurate.
3. Light touching Chinese character displayer operation panel,digital in putting and displaying, sealing, insulating, high corrosionresisting and easy operation.

Liquid Packaging Machine Specification

Packaging Materials OPP CPP
Bag size ( W ) : 30 - 150mm ( L ) : 30 - 170mm
Packing speed 15 - 60 bags / minute ( bag / min )
Measuring range 400ml
Total power 2KW
Voltage 220V or 380V50 - 60HZ
Machine size L930 x W730 x H1700mm
Machine weight 250kg
