Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Fully Automatic Horizontal Packaging Machine with PLC Control System Three Servos and 80-150bags/min Speed
Specifications
Brand Name :
Penglai
Model Number :
PL-250SE
Certification :
CE,SGS,TUV
Place of Origin :
China
MOQ :
1
Price :
4000-8000USD
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100Units
Delivery Time :
15-25 working days
Packaging Details :
Wooden Cases
Film Width :
Max. 350mm
Bag Length :
60-1000mm
Bag Width :
40-110mm
Packing Speed :
80-150bags/min
Voltage :
220V, 50/60Hz
Power :
2.4KW
Dimension :
3940*670*1320mm
Weight :
480kg
Warranty :
1 year warranty
After-sale service :
life-time online technical support, video support, spare parts suppliment
Description
Fully Automatic Horizontal Packaging Machine
High-efficiency industrial packaging equipment for bread, snacks, and various products with advanced automation and precision sealing capabilities.
Machine Function & Applications
This automatic pillow packaging machine delivers high-performance packaging solutions across multiple industries including food, daily chemical, pharmaceutical, and hardware sectors. The machine creates distinctive "pillow-shaped" packages that provide superior product protection with sealed structures and professional appearance.
Integrated automation system handles complete packaging workflow including automatic feeding, measuring, bag forming, sealing, cutting, coding, and counting functions. Advanced PLC control system with intuitive touch screen interface ensures simple parameter configuration and stable, high-precision operation.
Versatile design accommodates various regular-shaped products such as snacks (chips, candies, dried meat), daily necessities (toothbrushes, tissues), hardware components (screws, nuts), and pharmaceuticals (tablets, capsules). Compatible with multiple packaging materials including polyethylene film, polypropylene film, composite film, and aluminum foil. Customizable options available for date coding, tear notches, and transparent windows.
Key Features & Technical Advantages
  • Three-servo system enables instant bag length setting and cutting without empty travel adjustment
  • Color touch screen interface for convenient and rapid parameter configuration
  • Integrated fault self-diagnosis system with clear error display
  • High-sensitivity photoelectric eye color mark tracking with digital sealing and cutting position input
  • Independent PID temperature control optimized for various packaging materials
  • Positioning stop function prevents sticking and reduces film waste
  • Simplified transmission system ensures reliable operation and easy maintenance
  • Software-based control system facilitates function adjustments and technology upgrades
