4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches
Specifications
Brand Name :
PL
Model Number :
PL-350/550/850/1000
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD10000-14000
Payment Terms :
L/C,Western Union
Supply Ability :
500 units in a month
Delivery Time :
10-15 work days
Packaging Details :
wooden case
Product Name :
Multi-Lane Powder Shaped Pouch Machine
Lane Qty :
4/6/8/10 lanes (optional)
Max Speed :
30-50 bags/min/lane, total up to 300 ppm
Bag Size :
30-50 bags/min/lane, total up to 300 ppm
Control :
Siemens PLC + servo, 10" touch screen
Contact Part :
SUS304 (316L optional)
Air & Power :
0.65 MPa, 0.2 m³/min; 220 VAC 50 Hz 2.0-2.2 kW
Advantage :
CNC bag former, colour mark tracking, recipe memory
Description

4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches


Machine Overview


01. PenglaiPack multi-lane powder sachet machine is specially designed for high-speed packaging of collagen, coffee, probiotics and other stick & shaped powder pouches.
02. Available in 4/6 lanes, it realizes synchronous forming, filling, sealing and cutting, with 30–50 ppm per lane and max 300 ppm total output.
Adopting Inovance PLC and servo film pulling, it ensures ±1mm repeat precision. Independent PID temperature control supports pouch sizes of 40–170mm(L) × 16–84mm(W) with stable tension sealing.
03. CNC-machined lane dividers guarantee uniform sachet quality; 304/316L stainless steel product areas comply with GMP.
04. Standard features include safety door, photo-eye registration and self-diagnosis.
05. With a compact 1100×990mm footprint, it easily fits existing workshops and can be upgraded to a full automatic line with check-weigher and cartoner without re-validation.


Key attributes

packaging material
Plastic, Wood
packaging type
Bags, Film, Foil
application
Food, Commodity, Chemical, Machinery & Hardware
driven type
Electric
warranty
1 Year
Voltage
220V
function
FILLING, Wrapping, weighing and packaging
automatic grade
Automatic
video outgoing-inspection
Provided
machinery test report
Not Available
key selling points
Multifunctional
core components
motor, PLC
After-sales Service Provided
Video technical support, Field installation, commissioning and training, Online support, Field maintenance and repair service, Free spare parts
Weight (KG)
1050
place of origin
GUANGDONG
brand name
PENGLAI
dimension(l*w*h)
2100(L)X 900(W)X 1290(H)mm
Dosage
1-30 g
Main Function
Multi-Lane Powder Packing Machine
Bag width
Max 40 mm
Film width
Max 840 mm
Appearance
Stainless steel
Bag type
Back seal/three side seal/four side seal
Packing speed
40 Bags/min/lanes
Air consumption
0.4cbm/min, 0.6-0.8Mpa
Dimension
1100*1000*2300mm

4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches

4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches

4/6 Lane Powder Packing Machine 30-50 Ppm 220V Servo For Back Seal Pouches


FAQ
1. Can your machine meet our needs well?
After receiving your inquiry, we will confirm your packing material, packing volume, bag size, packing speed and precision, and any other requirments, and then give you the proposal according to your specific requirments. Every machine is customized to meet your needs well.
2. Are you factory or trading company?
We are the factory, and especially R&D, manufacture and sell various packing euipments. We have engaged in the packing R&D andproduction over 10 years.
3. What's your payment way?
T/T by our bank account directly, or by trade assurance service, or by West Union, or in cash
4. How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality
checking by yourself or by your contacts in Guangzhou.
5. We are afraid you won't send us the machine after we send you the money?
Please note our above business license and certificate. And if you don't trust us, then we can use trade assurance
service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
6. Why we should choose your company?
We are professtional in packing machines over 10 years, and we provide better after-sales service. You guarantee no risk for our deal.
