Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Mengo 200-K1 Electric Mini Car 3620*1610*1525 Lithium Iron Phosphate
Specifications
Brand Name :
BG
Model Number :
BG 4
Place of Origin :
China
MOQ :
1
Price :
USD9200
Payment Terms :
T/T
Supply Ability :
10000 UNIT PER YEAR
Delivery Time :
45 Working days
Packaging Details :
Container
Description
Specifications Sheet of Electric Hatchback -Mengo 2022 model
　
Version:MENGO-2022-V01 　 　 Issued Date:Oct.1,2022
产品配置
Version		 Mengo
200-K1		 Mengo
200-K2		 Mengo
200-K3		 Mengo
360-K1
FOB Qingdao $9,200 $9,800 $9,980 $12,900
NEDC综合续航里程(km)
Range,NEDC(km)		 200 200 200 335
基础参数Basic Parameter
长*宽*高(mm)
Dimension L*W*H (mm)		 3620*1610*1525
轴距(mm)
Wheelbase(mm)		 2440
最小离地间隙(mm)
Minimum Ground Clearance(mm)		 ≥150/123
整备质量(kg)
Kerb Weight (kg)		 860 860 860 995
轮胎规格
Tire		 165/65 R14
三电参数Motor & Battery&Controller
驱动电机类型
Type of Motor		 永磁同步电机
PMSM(Permanent Magnet Synchronous Motor)
峰值功率(kW)
Total Power of Motor		 25 25 25 35
峰值扭矩(N·m)
Total Toque of Motor		 105 105 105 125
0-50km/h加速时间(s)
Accelerating Time 0-50km/h (S)		 ＜10 ＜10 ＜10 ＜10
0-100km/h加速时间(s)
Accelerating Time 0-100km/h (S)		 ＜30 ＜30 ＜30 ＜20
最高车速(km/h)
Max. Speed(km/h)		 100 100 100 100
动力电池类型
Type of Battery		 磷酸铁锂
Lithium Iron Phosphate
电池容量(kWh)
Battery Capacity(kw*h)		 17.28 17.28 17.28 29.44
快充时间(min)(30%-80%)
Fast DC Charging Time(min)(30%-80%)		 / / / 30
慢充时间(h)(0%-100%)
Normal AC charging Time(h)(0%-100%)		 9-10 9-10 9-10 11-13
百公里耗电量(kWh)
Electricity Consumption per 100km (kWh)		 9.30 9.30 9.30 9.30
多媒体配置Multimedia
9寸中控彩色触屏
9-inch Central Control Colorful Touch Screen		 ● ● ● ●
手机互联/映射(安卓)
Mobilephone Interconnection/Map (Android)		 ● ● ● ●
FOTA ─ ─ ─ ─
车载蓝牙
Onboard Bluetooth		 ● ● ● ●
车载APP
Onboard APP		 ─ ─ ─ ─
USB接口
USB		 ● ● ● ●
扬声器
Speaker		 1 1 1 2
换挡显示
Shift Display		 ● ● ● ●
舒适便捷Comfort and Convenience Confirguration
内饰座椅风格
Seat Material		 织物
Fabrics		 仿皮
Artificial Leather		 仿皮
Artificial Leather		 仿皮
Artificial Leather
主驾驶座椅手动4向调节
Manual 4-way adjustment,Driver's seat		 ● ● ● ●
副驾驶座椅手动4向调节
Manual 4-way Adjustment,Front passenger's seat		 ● ● ● ●
后排座椅靠背整体放倒
Rear Seat Back All Foldable		 ● ● ● ●
方向盘材质
Steering Wheel Material		 发泡
Foamed		 发泡
Foamed		 仿皮
Artificial Leather		 发泡
Foamed
寻车功能
Car Searching Function		 ● ● ● ●
组合仪表(2.5寸)
Combined Instrument (2.5 inches)		 ● ● ● ─
数字仪表(7寸)
Digital Instrument (7 inches)		 ─ ─ ─ ●
外后视镜手动调节
Side Mirror with Manual Adjustment		 ● ● ● ●
内后视镜手动防眩目
Interior Manual Anti-glaring Rearview Mirror		 ─ ─ ─ ─
普通内后视镜
Normal Rearview Mirror		 ● ● ● ●
主驾驶遮阳板
Driver Sunvisor		 ● ● ● ●
副驾驶遮阳板
Front Passenger Sunvisor		 ● ● ● ●
前无骨雨刷
Front Boneless Wiper		 ● ● ● ●
电动空调
AC(Air Conditioning)		 ● ● ● ●
车辆盲区监测(BSD)
Blind Spot Detection (BSD)		 ─ ● ● ●
开门危险预警(DOW)
Door Open Warning (DOW)		 ─ ● ● ●
后方横向来车警示(RCTA)
Rear Cross Traffic Alert(RCTA)		 ─ ● ● ●
车载空气净化装置(带PM2.5显示)
Vehicle Air Purification Device( With PM2.5 Display)		 ─ ─ ─ ─
拖车钩
Tow Hook		 ● ● ● ●
三角警示牌
Triangle		 ● ● ● ●
荧光背心
Reflective Vest		 ● ● ● ●
安全呵护Safety Device
主副驾驶座安全气囊
Driver's / Front Passenger's Airbags		 ─ ●/─ ─ ●
前排普通三点式安全带
Front Three-point Seatbelt		 ● ● ● ●
后排普通三点式安全带
Rear Three-point Seatbelt		 ● ● ● ●
主驾驶安全带未系提示
Driver's Seatbelt Unfastened Reminder		 ● ● ● ●
副驾驶安全带未系提示
Front Passenger's Seatbelt Unfastened Reminder		 ─ ─ ─ ─
ISOFIX儿童座椅接口
ISOFIX Child's Seat Port		 ● ● ● ●
后门儿童安全锁
Rear Doors Child Safety Door Lock		 ● ● ● ●
胎压监测装置
Tyre Pressure Monitoring System(TPMS)		 ● ● ● ●
刹车优先系统
Brake Override System(BOS)		 ● ● ● ●
遥控钥匙
Remote Control Key		 ●(One) ●(One) ●(One) ●(One)
普通钥匙
Common Key		 ●(One) ●(One) ●(One) ●(One)
电子车身防盗系统
Electronic Vehicle Anti-theft System		 ● ● ● ●
车门未关警示
Door Open Warning		 ● ● ● ●
车内中控锁
Central Locking System		 ● ● ● ●
碰撞后自动解锁功能
Automatic Unlock Function After Collision		 ● ● ● ●
行车自动闭锁
Automatic Vehicle Locking System		 ● ● ● ●
尾门逃生开关
Tailgate Emergency Exit Switch		 ● ● ● ●
底盘系统Chassis
驱动形式
Driving Form		 后置后驱
Rear-drive		 前置前驱
Front-drive
前制动器类型
Front Brake		 盘式
Disc
后制动器类型
Rear Brake		 鼓式
Drum
驻车制动系统
Parking Brake		 机械手刹
Mechanical Hand Brake
助力类型
Type of Power Steering		 电动助力
EPS
机械式锁止防盗装置
Mechanical Lock Anti-theft Device		 ● ● ● ●
外观配置Exterior
钢轮辋
Steel Rim		 ● ● ● ●
后背门遥控解锁
Tailgate Remote Release		 ● ● ● ●
车顶行李架
Roof Rack		 ─ ─ ─ ─
鲨鱼鳍天线
Shark Fin Antenna		 ● ● ● ●
尾翼
Spoiler		 ● ● ● ●
卤素近光灯
Halogen Low Beam Lamp		 ● ● ● ●
卤素远光灯
Halogen High Beam Lamp		 ● ● ● ●
日间行车灯 (LED)
Day-time Running Lamp (LED)		 ─ ─ ─ ─
高位刹车灯
Hig-positioned Brake Lamp		 ● ● ● ●
前雾灯
Front Fog Lamp		 ─ ─ ─ ─
后雾灯
Rear Fog Lamp		 ● ● ● ●
外后视镜集成LED转向灯
Side Mirror Intergrated with LED Turning Signal		 ● ● ● ●
前排阅读灯
Front Row Reading Lamp		 ● ● ● ●
回家照明
Follow-me-Home Lamp		 ● ● ● ●
大灯高度可调
Height-adjustable Headlamp		 ● ● ● ●
“●”标配项；“〇”选装项；“─”无此项.
“●” Available ; “〇”Optional ; “─” Not Available
